ACSL-6400-00TE
Broadcom Limited
OPTOISO 2.5KV 4CH OPEN COLL 16SO
[IN STOCK] In Stock: 243 pcs
MOQ 1 · Tube · RoHS · EIA-481 · DAP/DDP · T/T
Technical specifications
| Parameter / Attribute | Specification / Value |
|---|---|
| Input type | DC |
| Output type | Open Collector, Schottky Clamped |
| Mounting | Surface Mount |
| Supply voltage | 3V ~ 5.5V |
| Voltage - isolation | 2500Vrms |
| Voltage - forward (Vf) | 1.52V |
| Current - output (Channel) | 50 mA |
| Current - DC forward (If) | 15mA |
| Operating temperature | -40°C ~ 100°C |
| Package | Tube |
| Data rate | 15MBd |
| Case | 16-SOIC (0.154\", 3.90mm Width) |
| Channels | 4 |
| Inputs - side 1/Side 2 | 4/0 |
| Rise (Fall time) | 30ns, 12ns |
| Propagation delay tpLH (tpHL) | 100ns, 100ns |
| Common mode transient immunity | 10kV/µs |
