SRP6540-8R2M
Bourns Inc.
[IN STOCK] In Stock: 16 pcs
MOQ 1 · Tape & Reel (TR); Cut Tape (CT) · RoHS · EIA-481 · DAP/DDP · T/T
Technical specifications
| Parameter / Attribute | Specification / Value |
|---|---|
| Type | Drum Core, Wirewound |
| Series | SRP6540 |
| Mounting | Surface Mount |
| Current rating | 4.5 A |
| Current - saturation | 5A |
| Inductance frequency - test | 100 kHz |
| Operating temperature | -55°C~125°C |
| Material - core | Iron Powder |
| Size (Dimension) | 0.283\" L x 0.256\" W (7.20mm x 6.50mm) |
| Height - seated | 0.157\" (4.00mm) |
| Package | Tape & Reel (TR); Cut Tape (CT) |
| Shielding | Shielded |
| Tolerance | ±20% |
| Inductance | 8.2 µH |
| Case | Nonstandard |
| DC resistance | 50.5mOhm Max |
