Active production — 2A switch, 100V output ceiling
The LT8361IMSE#TRPBF is an active-production boost/SEPIC regulator from Analog Devices, rated for a 2A switch current and a 100V maximum output voltage. Its 2.8V to 60V input range covers multi-cell Li-ion, 12V rails, and 48V telecom buses without an external bias supply.
Boost and SEPIC topology — single-inductor or coupled-inductor flexibility
The part supports both boost and SEPIC topologies, meaning a single BOM position can serve a step-up or an inverting/non-inverting SEPIC rail depending on the application need. The adjustable output type lets the feedback divider set the regulation point anywhere from the input voltage up to 100V, limited by the internal switch rating.
Package and board-fit — 16-MSOP-EP with exposed pad
The tape-and-reel option suits automated pick-and-place; cut-tape quantities are also available for prototype builds.
Temperature grade and compliance
ROHS3 compliant per the lifecycle record, with no halogenated flame retardants above the threshold — no special handling for RoHS-driven export markets.
