TPS5120DBTR
Texas Instruments
Tape & Reel (TR); Cut Tape (CT)-40°C ~ 85°C (TA)Step-Down
Ref. price$7.15
Lead time on requestGet quote
TPS5xxx Voltage Supervisors & Battery Chargers
4 variants · Texas Instruments
About the TPS5xxx Voltage Supervisors & Battery Chargers
The Texas Instruments TPS5xxx Voltage Supervisors & Battery Chargers series groups 4 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common clock sync of No, function of Step-Down and mounting of Surface Mount. Variants differ by case, control features and I/O channels, so you can match the exact case your application requires using the selection guide below. All listed TPS5xxx Voltage Supervisors & Battery Chargers part numbers are active and orderable.
Select a variant by
- Case
- 10-VFDFN Exposed Pad · 10-WFDFN Exposed Pad · 30-TFSOP (0.173\", 4.40mm Width) · 32-VFQFN Exposed Pad
- Control features
- Enable, Frequency Control, Power Good · Enable, Frequency Control, Power Good, Ramp · Enable, Power Good · Enable, Power Good, Soft Start
- I/O channels
- 1 · 2 · 3
- Operating temperature
- -40°C ~ 85°C (TA) · -10°C ~ 105°C (TA)
- Output phases
- 1 · 2 · 3
- Output type
- PWM Signal · Transistor Driver
- Synchronous rectifier
- No · Yes
- Voltage - supply (Vcc (Vdd))
- 2.5V ~ 24V · 4.5V ~ 6.5V · 4.5V ~ 13.2V · 4.5V ~ 28V
Shared specifications
- Clock sync
- No
- Function
- Step-Down
- Mounting
- Surface Mount
- Output configuration
- Positive
- Package
- Tape & Reel (TR); Cut Tape (CT)
- Topology
- Buck
Variant comparison
| Parameter | TPS51163DRCT | TPS5120DBTR | TPS51218DSCT | TPS53632RSMT |
|---|---|---|---|---|
| Case | 10-VFDFN Exposed Pad | 30-TFSOP (0.173\", 4.40mm Width) | 10-WFDFN Exposed Pad | 32-VFQFN Exposed Pad |
| Control features | Enable, Power Good | Enable, Power Good, Soft Start | Enable, Frequency Control, Power Good | Enable, Frequency Control, Power Good, Ramp |
| I/O channels | 1 | 2 | 1 | 3 |
| Operating temperature | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -10°C ~ 105°C (TA) |
| Output phases | 1 | 2 | 1 | 3 |
| Output type | Transistor Driver | Transistor Driver | Transistor Driver | PWM Signal |
| Synchronous rectifier | Yes | Yes | Yes | No |
| Voltage - supply (Vcc (Vdd)) | 4.5V ~ 13.2V | 4.5V ~ 28V | 4.5V ~ 6.5V | 2.5V ~ 24V |
Request a quote on any TPS5xxx Voltage Supervisors & Battery Chargers part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
