STMicroelectronics STM32F383RCY6TR — Microcontrollers & Processors (MCU / MPU / DSP)

STM32F383RCY6TR STM32F3 ARM Cortex-M4F MCU, 72 MHz

MPNSTM32F383RCY6TR
Active

STMicroelectronics STM32F383 series, STM32F383RCY6TR, 32-Bit Single-Core ARM Cortex-M4F MCU, 72 MHz, 256KB Flash, 32K x 8 RAM, 51 I/O, 66-WLCSP, -40 to 85 °C.

$10.9900Ref. price · indicative, final on quote
Independent supplier — new & surplus stockAuthenticity-screened · ESD-safe packingListing updated Jul 2026

Specifications

STM32F383RCY6TR specifications
ParameterValue
SeriesSTM32F3
MountingSurface Mount
Oscillator typeInternal
Program memory typeFLASH
Voltage - supply (Vcc (Vdd))1.65V ~ 1.95V
Operating temperature-40°C~85°C(TA)
Speed72MHz
PackageTape & Reel (TR)
RAM size32K x 8
Core size32-Bit Single-Core
PeripheralsDMA, POR, PWM, WDT
ConnectivityCANbus, HDMI-CEC, I²C, IrDA, LINbus, SPI, UART/USART
Number of i (O)51
Core processorARM® Cortex®-M4F
Case66-UFBGA, WLCSP
Data convertersA/D 16x12b, 21x16b; D/A 3x12b
Program memory size256KB (256K x 8)

Product details

Mixed-signal MCU in a wafer-level package

The 51 GPIOs are brought out in a 66-bump WLCSP (3.8 x 4.2 mm), a fine-pitch wafer-level chip-scale package that saves board area but demands careful PCB layout and assembly capability.

1.8 V supply rail — plan the power tree accordingly

The internal POR and BOR circuits are calibrated for this low-voltage domain, so brown-out thresholds will be lower than what you see on a 3.3 V part — factor that into the system reset strategy. The WLCSP package has a 0.4 mm ball pitch typically, so the PCB requires via-in-pad or microvia capability for routing.

No end-of-life notification, no last-time-buy window. If dual-sourcing is a concern, the STM32F3 series includes pin-compatible siblings with different Flash/RAM or package options — ST's product-change notification (PCN) process applies if any variant shifts status.

Frequently asked questions

What is the closest pin-compatible alternative to the STM32F383RCY6TR?

Within the STM32F383 series, the base product number STM32F383 shares the same pinout and package across Flash and RAM density options. For a direct drop-in, look at other STM32F383 parts in the same 66-WLCSP footprint — check the specific memory size and peripheral set against your firmware requirements.

Is the STM32F383RCY6TR RoHS compliant?

The STM32F383RCY6TR is an ST product and, as standard for ST's current portfolio, is manufactured RoHS-compliant. The 'Y' in the order code typically denotes a lead-free, RoHS-compliant finish. Verify the latest ST RoHS certificate for your specific batch if required by your compliance process.
