Skyworks Solutions SI8283CC-ISR
MPNSI8283CC-ISR
End of Life
DGTL ISO 5KV 1CH GATE DVR 24SOIC
$8.37Ref. price · indicative, final on quote
Packaging24-SOIC (0.295", 7.50mm Width)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Mounting | Surface Mount |
| Voltage - isolation | 5000Vrms |
| Voltage - output supply | 2.8V ~ 5.5V |
| Current - peak output | 4A |
| Current - output high, low | 2.5A, 3A |
| Operating temperature | -40°C ~ 125°C |
| Pulse width distortion | 5ns |
| Approval agency | CQC, CSA, UL, VDE |
| Grade | Automotive |
| Package | Tape & Reel (TR); Cut Tape (CT) |
| Technology | Capacitive Coupling |
| Qualification | AEC-Q100 |
| Case | 24-SOIC (0.295\", 7.50mm Width) |
| Channels | 1 |
| Rise (Fall time) | 5.5ns, 8.5ns |
| Propagation delay tpLH (tpHL) | 50ns, 50ns |
| Common mode transient immunity | 35kV/µs |
