Renesas R7F100GPN3CFA#AA0 RL78/G23 MCU, 16-Bit, 32MHz

MPNR7F100GPN3CFA#AA0
End of Life

Renesas RL78/G23 16-bit MCU, R7F100GPN3CFA#AA0, 32MHz core, 768KB Flash, 48K x 8 RAM, 8K x 8 EEPROM, 88 I/O, 100-LQFP, -40°C to 105°C, 1.8V to 5.5V.

$6.44Ref. price · indicative, final on quote
R7F100GPN3CFA#AA0 datasheet
Packaging100-LQFP
StockContact for availability
MOQ1 pcs
  • 100% new & originalTraceable channels only — no refurbs, no pulls, no remarked parts.
  • Date & lot codes on quoteStated per line before you commit; label photos on request.
  • MSL-compliant ESD packingMoisture-sealed bags with indicator cards; reels photo-verified.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.

Specifications

R7F100GPN3CFA#AA0 Technical Specifications
ParameterValue
SeriesRL78/G23
Mounting typeSurface Mount
Oscillator typeInternal
Program memory typeFLASH
Voltage - supply (Vcc (Vdd))1.8V ~ 5.5V
Operating temperature-40°C ~ 105°C (TA)
Speed32MHz
PackageTray
RAM size48K x 8
Core size16-Bit
EEPROM size8K x 8
PeripheralsCapacitive Touch, LVD, POR, PWM, WDT
ConnectivityCSI, I²C, LINbus, SPI, UART/USART
Number of i (O)88
Core processorRL78
Case100-LQFP
Data convertersA/D 20x10b, 8x12b; D/A 2x8b
Program memory size768KB (768K x 8)

Product details

16-bit RL78/G23 MCU for industrial control and HMI

The Renesas R7F100GPN3CFA#AA0 is a 16-bit RL78/G23 microcontroller with a 32 MHz core, 768 KB Flash, 48 KB RAM, and 8 KB EEPROM. It has 88 I/O lines in a 100-LQFP package and integrates capacitive touch, LVD, POR, PWM, and WDT. Data converters include A/D 20x10b, 8x12b and D/A 2x8b. Supply range is 1.8 V to 5.5 V, operating temperature -40°C to 105°C.

768 KB Flash and 48 KB RAM — what it means for the BOM

The 768 KB Flash is large enough to hold a full Modbus TCP stack, a capacitive-touch library, and a local HMI frame buffer without external memory. The 48 KB RAM supports moderate data logging and multi-protocol buffering. The 8 KB EEPROM (emulated or dedicated) stores calibration constants and node configuration across power cycles — no external serial EEPROM needed, saving a BOM line.

Connectivity and peripheral set

Serial interfaces include CSI, I²C, LINbus, SPI, and UART/USART — enough for sensor buses, display links, and LIN nodes in automotive-adjacent applications. The capacitive-touch unit handles up to 20 channels for membrane keypads or proximity sliders without a dedicated touch controller. Internal oscillator eliminates the external crystal for most timing tasks, though an external clock can still be fed in.

Frequently asked questions

Is R7F100GPN3CFA#AA0 RoHS compliant?

Yes, it is ROHS3 compliant.

What is the closest functional equivalent to R7F100GPN3CFA#AA0?

The R7F100GPG3CFB#AA0 is a close functional peer within the RL78/G23 series, sharing the same 32 MHz core, 88 I/O, 100-pin LQFP package, and peripheral set including capacitive touch, LVD, POR, PWM, WDT, and the same data converters (A/D 20x10b, 8x12b; D/A 2x8b). The key difference is program memory: the R7F100GPN3CFA#AA0 carries 768 KB Flash, while the R7F100GPG3CFB#AA0 carries a smaller Flash size. Verify memory requirements before substituting.

Where can I buy R7F100GPN3CFA#AA0?

This part is sourced to order. Availability and pricing are confirmed at quote time.
