AT25DF011-SSHN-T
Renesas Electronics Corporation
Tape & Reel (TR) Cut Tape (CT)-40°C ~ 85°C (TC)FLASH
Ref. price$0.7000
Lead time on requestGet quote
Renesas Electronics Corporation AT25 Series
256 variants · Renesas Electronics Corporation
About the Renesas Electronics Corporation AT25 Series
The Renesas Electronics Corporation AT25 Series series groups 256 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common memory format of FLASH, memory interface of SPI and memory type of Non-Volatile. Variants differ by case, frequency and memory organization, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 8-SOIC (0.154\", 3.90mm Width) · 8-TSSOP (0.173\", 4.40mm Width) · 8-UDFN Exposed Pad · 8-UFDFN Exposed Pad
- Frequency
- 85 MHz · 104 MHz
- Memory organization
- 128K x 8 · 256K x 8
- Memory size
- 1Mbit · 2Mbit
- Operating temperature
- -40°C ~ 85°C (TC) · -40°C ~ 125°C (TC)
- Voltage
- 1.65V ~ 3.6V · 1.7V ~ 3.6V
- Write cycle time - word, page
- 8µs, 2.5ms · 8µs, 3.5ms · 12µs, 5ms
Shared specifications
- Memory format
- FLASH
- Memory interface
- SPI
- Memory type
- Non-Volatile
- Mounting
- Surface Mount
- Package
- Tape & Reel (TR) Cut Tape (CT)
- Technology
- FLASH
Variant comparison
| Parameter | AT25DF011-SSHNHR-T | AT25DF011-SSHN-T | AT25DF011-XMHNHR-T | AT25DF011-XMHN-T | AT25DF021A-MAHNHR-T | AT25DF021A-MAHN-T |
|---|---|---|---|---|---|---|
| Case | 8-SOIC (0.154\", 3.90mm Width) | 8-SOIC (0.154\", 3.90mm Width) | 8-TSSOP (0.173\", 4.40mm Width) | 8-TSSOP (0.173\", 4.40mm Width) | 8-UFDFN Exposed Pad | 8-UFDFN Exposed Pad |
| Frequency | 104 MHz | 104 MHz | 104 MHz | 104 MHz | 85 MHz | 104 MHz |
| Memory organization | 128K x 8 | 128K x 8 | 128K x 8 | 128K x 8 | 256K x 8 | 256K x 8 |
| Memory size | 1Mbit | 1Mbit | 1Mbit | 1Mbit | 2Mbit | 2Mbit |
| Operating temperature | -40°C ~ 85°C (TC) | -40°C ~ 85°C (TC) | -40°C ~ 125°C (TC) | -40°C ~ 85°C (TC) | -40°C ~ 125°C (TC) | -40°C ~ 85°C (TC) |
| Voltage | 1.65V ~ 3.6V | 1.65V ~ 3.6V | 1.7V ~ 3.6V | 1.65V ~ 3.6V | 1.7V ~ 3.6V | 1.65V ~ 3.6V |
| Write cycle time - word, page | 8µs, 3.5ms | 8µs, 3.5ms | 12µs, 5ms | 8µs, 3.5ms | 12µs, 5ms | 8µs, 2.5ms |
Request a quote on any Renesas Electronics Corporation AT25 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
