FDMS030N06B
onsemi
Tape & Reel (TR); Cut Tape (CT)-55°C~150°C(TJ)PowerTrench®
Ref. price$3.1100
Lead time on requestGet quote ›
onsemi FDMS Series
40 variants · onsemi
About the onsemi onsemi FDMS Series series
The onsemi onsemi FDMS Series series groups 40 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common FET feature of - and mounting type of Surface Mount. Variants differ by case, current - continuous drain (Id) @ 25°C and FET type, so you can match the exact case your application requires using the selection guide below. The range mixes active and legacy part numbers, so you can source both current onsemi FDMS Series variants and discontinued ones from a single page.
Select a variant by
- Case
- 8-PowerTDFN · 8-PowerVDFN
- Current - continuous drain (Id) @ 25°C
- 9A (Ta), 18A (Tc) · 15.2A (Ta), 28A (Tc) · 19A (Ta), 42A (Tc) · 19A (Ta), 136A (Tc) · 19.4A (Ta), 100A (Tc) · 21A (Ta), 42A (Tc) · 22.1A (Ta), 100A (Tc) · 23A (Ta), 49A (Tc) · 25A (Ta), 42A (Tc) · 35A (Tc) · 36A (Ta), 100A (Tc) · 47A (Ta), 100A (Tc)
- FET type
- N-Channel · P-Channel
- Operating temperature
- -55°C ~ 150°C (TJ) · -55°C~150°C(TJ) · -55°C~175°C(TJ)
- Package
- Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT)
- Rds on (Max) @ id, vgs
- 0.99mOhm @ 36A, 10V · 2.8mOhm @ 25A, 10V · 2.9mOhm @ 23A, 10V · 3mOhm @ 50A, 10V · 3.5mOhm @ 45A, 10V · 3.8mOhm @ 21A, 10V · 3.9mOhm @ 50A, 10V · 4.9mOhm @ 18A, 10V · 6.8mOhm @ 15.2A, 10V · 15mOhm @ 16.5A, 10V · 20mOhm @ 9A, 10V
- Vgs(th) (Max) @ id
- 2.5V @ 250µA · 2.7V @ 250µA · 3V @ 1mA · 3V @ 250µA · 4.5V @ 250µA
Variant comparison
| Parameter | FDMS030N06B | FDMS0312S | FDMS039N08B | FDMS3D5N08LC | FDMS4435BZ | FDMS5361L-F085 |
|---|---|---|---|---|---|---|
| Case | 8-PowerTDFN | 8-PowerTDFN | 8-PowerTDFN | 8-PowerTDFN | 8-PowerTDFN | 8-PowerVDFN |
| Current - continuous drain (Id) @ 25°C | 22.1A (Ta), 100A (Tc) | 19A (Ta), 42A (Tc) | 19.4A (Ta), 100A (Tc) | 19A (Ta), 136A (Tc) | 9A (Ta), 18A (Tc) | 35A (Tc) |
| FET type | N-Channel | N-Channel | N-Channel | N-Channel | P-Channel | N-Channel |
| Operating temperature | -55°C~150°C(TJ) | -55°C~150°C(TJ) | -55°C ~ 150°C (TJ) | -55°C~150°C(TJ) | -55°C~150°C(TJ) | -55°C~175°C(TJ) |
| Package | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) |
| Rds on (Max) @ id, vgs | 3mOhm @ 50A, 10V | 4.9mOhm @ 18A, 10V | 3.9mOhm @ 50A, 10V | 3.5mOhm @ 45A, 10V | 20mOhm @ 9A, 10V | 15mOhm @ 16.5A, 10V |
| Vgs(th) (Max) @ id | 4.5V @ 250µA | 3V @ 1mA | 4.5V @ 250µA | 2.5V @ 250µA | 3V @ 250µA | 3V @ 250µA |
Shared specifications
- FET feature
- -
- Mounting type
- Surface Mount
Request a quote on any onsemi FDMS Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the onsemi onsemi FDMS Series variants differ?
- onsemi FDMS Series part numbers differ by case, current - continuous drain (Id) @ 25°C, FET type and operating temperature. Use the selection guide above to pick by case.
- How many onsemi onsemi FDMS Series part numbers are listed?
- 40 onsemi onsemi FDMS Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for onsemi onsemi FDMS Series?
- Request a quote (RFQ) for any onsemi FDMS Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
