PCA9532PW,112
NXP Semiconductors
TubePower Switch-40°C ~ 85°C (TA)
Ref. price$3.2
Lead time on requestGet quote
NXP Semiconductors PCA9 Analog Series
7 variants · NXP Semiconductors
About the NXP Semiconductors PCA9 Analog Series
The NXP Semiconductors PCA9 Analog Series series groups 7 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common mounting of Surface Mount. Variants differ by case, package and voltage, so you can match the exact case your application requires using the selection guide below. All listed NXP Semiconductors PCA9 Analog Series part numbers are active and orderable.
Select a variant by
- Case
- 8-VFDFN Exposed Pad · 8-WFDFN Exposed Pad · 14-TSSOP (0.173\", 4.40mm Width) · 16-TSSOP (0.173\", 4.40mm Width) · 24-TSSOP (0.173\", 4.40mm Width) · 28-TSSOP (0.173\", 4.40mm Width) Exposed Pad
- Package
- Tape & Reel (TR); Cut Tape (CT) · Tube
- Voltage
- 0.8V ~ 5.5V, 2.2V ~ 5.5V · 1.65V ~ 5.5V · 2.3V ~ 3.6V, 4.5V ~ 5.5V · 2.3V ~ 5.5V · 5.5V
- Operating temperature
- -40°C ~ 85°C · -40°C ~ 85°C (TA)
- Applications
- 2-Channel I²C Multiplexer · Backlight · I²C
- Type
- Buffer, ReDriver · Linear · Power Switch
- Current - output (Channel)
- 25mA · 57mA
- Dimming
- I²C · PWM
Shared specifications
- Mounting
- Surface Mount
Variant comparison
| Parameter | PCA9532PW,112 | PCA9538APWJ | PCA9633TK,118 | PCA9670PW,118 | PCA9952TW/Q900,118 | PCA9617ATPZ |
|---|---|---|---|---|---|---|
| Case | 24-TSSOP (0.173\", 4.40mm Width) | 16-TSSOP (0.173\", 4.40mm Width) | 8-VFDFN Exposed Pad | 16-TSSOP (0.173\", 4.40mm Width) | 28-TSSOP (0.173\", 4.40mm Width) Exposed Pad | 8-WFDFN Exposed Pad |
| Package | Tube | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) |
| Voltage | 5.5V | 1.65V ~ 5.5V | 5.5V | 2.3V ~ 5.5V | 5.5V | 0.8V ~ 5.5V, 2.2V ~ 5.5V |
| Operating temperature | -40°C ~ 85°C (TA) | -40°C ~ 85°C | -40°C ~ 85°C (TA) | -40°C ~ 85°C | -40°C ~ 85°C (TA) | -40°C ~ 85°C |
| Applications | Backlight | — | Backlight | — | Backlight | I²C |
| Type | Power Switch | — | Power Switch | — | Linear | Buffer, ReDriver |
| Current - output (Channel) | 25mA | — | 25mA | — | 57mA | — |
| Dimming | I²C | — | PWM | — | PWM | — |
Request a quote on any NXP Semiconductors PCA9 Analog Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
