NXP PCA9532PW,112 I²C LED Driver, 16-Ch 25mA, 24-TSSOP

MPNPCA9532PW,112
End of Life

NXP Semiconductors PCA9532PW,112 I²C-bus LED driver, Power Switch type, 16 outputs, 25 mA per channel, I²C dimming, 24-TSSOP package, Tube.

$3.2Ref. price · indicative, final on quote
PCA9532PW,112 datasheet
Packaging24-TSSOP (0.173", 4.40mm Width)
StockContact for availability
Lead time3-5 Days wk
MOQ1 pcs
  • 100% new & originalTraceable channels only — no refurbs, no pulls, no remarked parts.
  • Date & lot codes on quoteStated per line before you commit; label photos on request.
  • MSL-compliant ESD packingMoisture-sealed bags with indicator cards; reels photo-verified.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.

Specifications

PCA9532PW,112 Technical Specifications
ParameterValue
TypePower Switch
Mounting typeSurface Mount
Voltage5.5V
Current - output (Channel)25mA
Number of outputs16
Operating temperature-40°C ~ 85°C (TA)
DimmingI²C
PackageTube
ApplicationsBacklight
Case24-TSSOP (0.173\", 4.40mm Width)
Internal switchYes

Product details

16-channel I²C LED driver for backlight and indicator arrays

The PCA9532PW,112 from NXP Semiconductors is an I²C-bus controlled LED driver with 16 open-drain outputs, each rated for 25 mA continuous current. The Power Switch type means each output acts as a constant-current sink, controlled via the I²C interface for individual on/off and PWM dimming — ideal for backlighting keypads, LCD panels, or status indicator arrays in embedded systems.

The surface-mount package keeps the component height low for tight enclosures. The internal switches (open-drain NMOS) eliminate the need for external driver transistors for most LED loads up to 25 mA per channel — the I²C bus handles the dimming protocol directly, reducing BOM count.

Active production and compliance

No pin-compatible second-source or successor is listed — the NXP PCA9532 family is the primary reference.

Frequently asked questions

What is PCA9532PW,112's output drive capability?

Each of the 16 outputs sinks up to 25 mA continuous at rated supply voltage. The I²C interface controls individual output states and supports PWM dimming for LED brightness adjustment.

What supply voltage range does PCA9532PW,112 require?

The I²C bus voltage follows the VDD supply rail.
