Peripheral set and memory interface
Three USB 2.0 ports are available. The DDR RAM controller keeps memory bandwidth matched to the 532 MHz core for smooth graphics and media playback. Graphics acceleration is built in, and the display controller drives LCD panels directly. The multimedia co-processors offload video encode/decode and vector floating-point math from the ARM core.
I/O voltage flexibility and interface count
The I/O voltage range spans 1.8 V through 3.0 V, so this processor can interface directly with legacy 2.5 V peripherals and modern 1.8 V DDR memory without level shifters on every line. The list of additional interfaces covers I²C, SPI, UART, I²S for audio, MMC/SD/SDIO for storage, PCMCIA for expansion cards, and a 1-Wire interface for battery-monitoring or authentication chips. Security features (random number generator, secure JTAG, secure memory, fuse box) are included for designs that need encrypted boot or tamper detection.
Sourcing and lifecycle
No NRND or last-time-buy notice is in effect. For a BOM line that needs a proven application processor with industrial temperature range and a mature software ecosystem, this part avoids the supply-chain risk of a phasing-out device.
