74LVC1G175GM,115
Nexperia USA Inc.
Tape & Reel (TR) Cut Tape (CT)-40°C ~ 125°C (TA)200 MHz
Ref. price$0.4900
Lead time on requestGet quote ›
Nexperia USA Inc. 74LVC Series
39 variants · Nexperia USA Inc.
About the Nexperia USA Inc. Nexperia USA Inc. 74LVC Series series
The Nexperia USA Inc. Nexperia USA Inc. 74LVC Series series groups 39 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common current - output high, low of 32mA, 32mA, frequency of 200 MHz and mounting type of Surface Mount. Variants differ by case, current - quiescent and function, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 6-TSSOP, SC-88, SOT-363 · 6-XFDFN · 8-TSSOP, 8-MSOP (0.118\", 3.00mm Width) · 8-VFSOP (0.091\", 2.30mm Width) · 8-XFDFN · SC-74, SOT-457
- Current - quiescent
- 4 µA · 10 µA · 40 µA
- Function
- Reset · Set(Preset) and Reset
- Input capacitance
- 2.5 pF · 4 pF
- Max propagation delay @ v, max CL
- 4ns @ 5V, 50pF · 4.1ns @ 5V, 50pF
- Operating temperature
- -40°C ~ 125°C (TA) · -40°C~125°C(TA)
- Output type
- Complementary · Non-Inverted
- Package
- Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT)
Variant comparison
| Parameter | 74LVC1G175GM,115 | 74LVC1G175GM,132 | 74LVC1G175GS,132 | 74LVC1G175GV,125 | 74LVC1G175GW,125 | 74LVC1G175GW-Q100H |
|---|---|---|---|---|---|---|
| Case | 6-XFDFN | 6-XFDFN | 6-XFDFN | SC-74, SOT-457 | 6-TSSOP, SC-88, SOT-363 | 6-TSSOP, SC-88, SOT-363 |
| Current - quiescent | 40 µA | 40 µA | 40 µA | 40 µA | 40 µA | 10 µA |
| Function | Reset | Reset | Reset | Reset | Reset | Reset |
| Input capacitance | 2.5 pF | 2.5 pF | 2.5 pF | 2.5 pF | 2.5 pF | 2.5 pF |
| Max propagation delay @ v, max CL | 4ns @ 5V, 50pF | 4ns @ 5V, 50pF | 4ns @ 5V, 50pF | 4ns @ 5V, 50pF | 4ns @ 5V, 50pF | 4ns @ 5V, 50pF |
| Operating temperature | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) |
| Output type | Non-Inverted | Non-Inverted | Non-Inverted | Non-Inverted | Non-Inverted | Non-Inverted |
| Package | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) |
Shared specifications
- Current - output high, low
- 32mA, 32mA
- Frequency
- 200 MHz
- Mounting type
- Surface Mount
- Number of bits per element
- 1
- Number of elements
- 1
- Trigger type
- Positive Edge
- Type
- D-Type
- Voltage
- 1.65V ~ 5.5V
Request a quote on any Nexperia USA Inc. 74LVC Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Nexperia USA Inc. Nexperia USA Inc. 74LVC Series variants differ?
- Nexperia USA Inc. 74LVC Series part numbers differ by case, current - quiescent, function and input capacitance. Use the selection guide above to pick by case.
- How many Nexperia USA Inc. Nexperia USA Inc. 74LVC Series part numbers are listed?
- 39 Nexperia USA Inc. Nexperia USA Inc. 74LVC Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Nexperia USA Inc. Nexperia USA Inc. 74LVC Series?
- Request a quote (RFQ) for any Nexperia USA Inc. 74LVC Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
