DSC8001AI2-PROGRAMMABLE
Microchip Technology
-40°C ~ 85°CTubeXO (Standard)
Ref. price$9.4900
Lead time on requestGet quote
Microchip Technology DSC8001 Series
52 variants · Microchip Technology
About the Microchip Technology DSC8001 Series
The Microchip Technology DSC8001 Series series groups 52 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common available frequency range of 1 MHz ~ 150 MHz, base resonator of MEMS and current - supply of 12.2mA. Variants differ by case, frequency stability and frequency stability (Total), so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 4-SMD, No Lead · 4-SMD, No Lead Exposed Pad
- Frequency stability
- - · ±10ppm · ±25ppm
- Frequency stability (Total)
- - · ±10ppm · ±25ppm · ±50ppm
- Operating temperature
- -40°C ~ 85°C · -40°C ~ 105°C · -40°C~85°C · -40°C~105°C
- Package
- Tape & Reel (TR) · Tube
- Size (Dimension)
- 0.197\" L x 0.126\" W (5.00mm x 3.20mm) · 0.276\" L x 0.197\" W (7.00mm x 5.00mm)
Shared specifications
- Available frequency range
- 1 MHz ~ 150 MHz
- Base resonator
- MEMS
- Current - supply
- 12.2mA
- Current - supply (Disable)
- 15 µA
- Function
- Standby
- Height - seated
- 0.035\" (0.90mm)
- Mounting
- Surface Mount
- Output
- CMOS
- Ratings
- AEC-Q100
- Spread spectrum bandwidth
- -
- Type
- XO (Standard)
- Voltage
- 1.8V ~ 3.3V
Variant comparison
| Parameter | DSC8001AI1 | DSC8001AI1-PROGRAMMABLE | DSC8001AI2 | DSC8001AI2-PROGRAMMABLE | DSC8001AI2T | DSC8001AI5 |
|---|---|---|---|---|---|---|
| Case | 4-SMD, No Lead | 4-SMD, No Lead | 4-SMD, No Lead | 4-SMD, No Lead | 4-SMD, No Lead Exposed Pad | 4-SMD, No Lead |
| Frequency stability | - | - | - | - | ±25ppm | - |
| Frequency stability (Total) | ±50ppm | ±50ppm | ±25ppm | ±25ppm | - | ±10ppm |
| Operating temperature | -40°C~85°C | -40°C ~ 85°C | -40°C~85°C | -40°C ~ 85°C | -40°C~85°C | -40°C~85°C |
| Package | Tube | Tube | Tube | Tube | Tape & Reel (TR) | Tube |
| Size (Dimension) | 0.276\" L x 0.197\" W (7.00mm x 5.00mm) | 0.276\" L x 0.197\" W (7.00mm x 5.00mm) | 0.276\" L x 0.197\" W (7.00mm x 5.00mm) | 0.276\" L x 0.197\" W (7.00mm x 5.00mm) | 0.276\" L x 0.197\" W (7.00mm x 5.00mm) | 0.276\" L x 0.197\" W (7.00mm x 5.00mm) |
Request a quote on any Microchip Technology DSC8001 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
