Key switching parametrics for the fit decision
The IRFB7446GPBF: This is an N-channel MOSFET rated for 40 V drain-source and 120 A continuous switching current. The max Rds(on) is 3.3 mOhm at 70 A and 10 V gate drive — that low on-resistance keeps conduction losses down in high-current paths like motor drives or power supplies. Gate charge is 93 nC max at 10 V, and input capacitance is 3.2 nF. The gate drive requirement is modest for a 120 A device — a standard 1 A gate driver can switch it at moderate frequencies without excessive cross-conduction. Maximum power dissipation is 99 W, and the gate threshold voltage is 3.9 V at 100 µA drain current. The ±20 V gate-source rating gives headroom for gate-drive overshoot in noisy environments.
Package and mounting — field-service perspective
Housed in a TO-220 through-hole package, supplied in bulk. The three-lead layout is standard — gate, drain, and source are clearly marked on the body, and the tab is drain. No special orientation ambiguity; a tech with a soldering iron and a heatsink can swap it on site without a rework station. Part of the HEXFET and StrongIRFET series — Infineon's trench-gate MOSFET family optimised for low Rds(on) and rugged avalanche capability.
