Infineon Technologies IMZ120R030M1HXKSA1
MPNIMZ120R030M1HXKSA1
End of Life
SICFET N-CH 1.2KV 56A TO247-4
$14.80440Price · pay online now
PackagingTO-247-4
RoHSROHS3 Compliant
SeriesCoolSiC™
Independent supplier — new & surplus stockAuthenticity-screened · ESD-safe packingListing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Series | CoolSiC™ |
| FET type | N-Channel |
| Mounting | Through Hole |
| Drain to source voltage | 1200 V |
| Drive voltage (Max rds on, min rds on) | 15V, 18V |
| Current - continuous drain (Id) @ 25°C | 56A (Tc) |
| Power dissipation | 227W (Tc) |
| Operating temperature | -55°C ~ 175°C (TJ) |
| Package | Tube |
| Vgs | +23V, -7V |
| Technology | SiCFET (Silicon Carbide) |
| Case | TO-247-4 |
| Vgs(th) (Max) @ id | 5.7V @ 10mA |
| Rds on (Max) @ id, vgs | 40mOhm @ 25A, 18V |
| Gate charge (Qg) (Max) @ vgs | 63 nC @ 18 V |
| Input capacitance (Ciss) (Max) @ vds | 2120 pF @ 800 V |
