Chemi-Con — Specialty Capacitors

Chemi-Con Specialty Capacitors — 15 part numbers with specifications and datasheets. Filter by key specs and request a quote on ICBOMS.

Capacitance
1.5 mF · 330 µF · 560 µF · 680 µF
Ripple Current @ High Frequency
7.5 A @ 100 kHz · 5.08 A @ 100 kHz · 6.1 A @ 100 kHz · 5 A @ 100 kHz
ESR (Equivalent Series Resistance)
8mOhm · 10mOhm · 14mOhm · 30mOhm
Height - Seated (Max)
0.846" (21.50mm) · 0.354" (9.00mm) · 0.512" (13.00mm) · 0.236" (6.00mm)
Ripple Current @ Low Frequency
750 mA @ 120 Hz · 508 mA @ 120 Hz · 610 mA @ 120 Hz · 500 mA @ 120 Hz
Lead Spacing
0.138" (3.50mm) · 0.098" (2.50mm) · 0.197" (5.00mm) · -
Surface Mount Land Size
- · 0.406" L x 0.406" W (10.30mm x 10.30mm) · 0.260" L x 0.260" W (6.60mm x 6.60mm) · 0.327" L x 0.327" W (8.30mm x 8.30mm)
Lifetime @ Temp.
20000 Hrs @ 105°C · 15000 Hrs @ 105°C · 3000 Hrs @ 105°C
