HCPL-0201#500
Broadcom Limited
4.5V ~ 20VTape & Reel (TR) Cut Tape (CT)5MBd
Ref. price$5.9800
Lead time on requestGet quote ›
Broadcom Limited HCPL Series
151 variants · Broadcom Limited
About the Broadcom Limited Broadcom Limited HCPL Series series
The Broadcom Limited Broadcom Limited HCPL Series series groups 151 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common case of 8-SOIC (0.154\", 3.90mm Width), mounting type of Surface Mount and number of channels of 1. Variants differ by current - DC forward (If), operating temperature and package, so you can match the exact current - DC forward (If) your application requires using the selection guide below.
Select a variant by
- Current - DC forward (If)
- 5mA (Typ) · 10mA · 20 mA · 25 mA · 25mA
- Operating temperature
- -55°C ~ 100°C · -40°C ~ 85°C · -40°C ~ 100°C
- Package
- Tape & Reel (TR) · Tape & Reel (TR) Cut Tape (CT) · Tube
- Rise (Fall time)
- - · 30ns, 7ns · 40ns, 20ns · 50ns, 50ns
- Voltage - forward (Vf)
- 1.3V · 1.5V
- Current - output (Channel)
- 8mA · 15 mA · 25 mA
- Output type
- Open Collector, Schottky Clamped · Push-Pull, Totem Pole · Transistor · Transistor with Base
- Common mode transient immunity
- 1kV/µs · 5kV/µs, 10kV/µs · 10kV/µs · 15kV/µs · 100V/µs
Variant comparison
| Parameter | HCPL-0201#500 | HCPL-0211 | HCPL-0211#500 | HCPL-0300-000E | HCPL-0300-500E | HCPL-0302-000E |
|---|---|---|---|---|---|---|
| Current - DC forward (If) | 10mA | 10mA | 10mA | 5mA (Typ) | 5mA (Typ) | 20 mA |
| Operating temperature | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 100°C |
| Package | Tape & Reel (TR) Cut Tape (CT) | Tube | Tape & Reel (TR) | Tube | Tape & Reel (TR) Cut Tape (CT) | Tube |
| Rise (Fall time) | 30ns, 7ns | 30ns, 7ns | 30ns, 7ns | 40ns, 20ns | 40ns, 20ns | 50ns, 50ns |
| Voltage - forward (Vf) | 1.5V | 1.5V | 1.5V | 1.3V | 1.3V | 1.5V |
| Current - output (Channel) | 25 mA | 25 mA | 25 mA | 25 mA | 25 mA | — |
| Output type | Push-Pull, Totem Pole | Push-Pull, Totem Pole | Push-Pull, Totem Pole | Open Collector, Schottky Clamped | Open Collector, Schottky Clamped | — |
| Common mode transient immunity | 1kV/µs | 5kV/µs, 10kV/µs | 5kV/µs, 10kV/µs | 100V/µs | 100V/µs | 10kV/µs |
Shared specifications
- Case
- 8-SOIC (0.154\", 3.90mm Width)
- Mounting type
- Surface Mount
- Number of channels
- 1
- Voltage - isolation
- 3750Vrms
Request a quote on any Broadcom Limited HCPL Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Broadcom Limited Broadcom Limited HCPL Series variants differ?
- Broadcom Limited HCPL Series part numbers differ by current - DC forward (If), operating temperature, package and rise (Fall time). Use the selection guide above to pick by current - DC forward (If).
- How many Broadcom Limited Broadcom Limited HCPL Series part numbers are listed?
- 151 Broadcom Limited Broadcom Limited HCPL Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Broadcom Limited Broadcom Limited HCPL Series?
- Request a quote (RFQ) for any Broadcom Limited HCPL Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
