MAX5023MASA+
Analog Devices
Tube-40°C ~ 125°C< 1 A
Ref. price$5.41
Lead time on requestGet quote
Analog Devices MAX5 Dc Dc Modules Series
120 variants · Analog Devices
About the Analog Devices MAX5 Dc Dc Modules Series
The Analog Devices MAX5 Dc Dc Modules Series series groups 120 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common mounting of Surface Mount. Variants differ by case, operating temperature and package, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 8-SOIC (0.154\", 3.90mm Width) · 8-SOIC (0.154\", 3.90mm Width) Exposed Pad · 16-SOIC (0.295\", 7.50mm Width) · SOT-23-6
- Operating temperature
- -40°C ~ 85°C · -40°C ~ 125°C · -40°C ~ 125°C (TJ) · -40°C ~ 150°C (TJ) · 0°C ~ 85°C (TA)
- Package
- Tape & Reel (TR); Cut Tape (CT) · Tube
- Output type
- Adjustable · Fixed · Voltage - Buffered
- Output current
- 1A · 150mA · 500mA
- Voltage - input
- 65V · 76V
- Voltage - output (Min (Fixed))
- 1.25V · 3.3V · 5V
Shared specifications
- Mounting
- Surface Mount
Variant comparison
| Parameter | MAX500BEWE+ | MAX5023LASA+ | MAX5023MASA+ | MAX5023TASA+ | MAX5033AASA+ | MAX5035AASA+ |
|---|---|---|---|---|---|---|
| Case | 16-SOIC (0.295\", 7.50mm Width) | 8-SOIC (0.154\", 3.90mm Width) | 8-SOIC (0.154\", 3.90mm Width) | 8-SOIC (0.154\", 3.90mm Width) Exposed Pad | 8-SOIC (0.154\", 3.90mm Width) | 8-SOIC (0.154\", 3.90mm Width) |
| Operating temperature | -40°C ~ 85°C | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) |
| Package | Tube | Tube | Tube | Tube | Tube | Tube |
| Output type | Voltage - Buffered | Fixed | Fixed | Fixed | Fixed | Fixed |
| Output current | — | 150mA | 150mA | 150mA | 500mA | 1A |
| Voltage - input | — | 65V | 65V | 65V | 76V | 76V |
| Voltage - output (Min (Fixed)) | — | 5V | 5V | 3.3V | 3.3V | 3.3V |
Request a quote on any Analog Devices MAX5 Dc Dc Modules Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
