Analog Devices MAX9736AETJ+ — Analog & Data Acquisition

MAX9736AETJ+ Class D Audio Amp, 35W Mono / 17.5W Stereo

MPNMAX9736AETJ+
End of Life

Analog Devices MAX9736AETJ+, Class D audio amplifier, 35W mono into 4Ω or 17.5W stereo into 8Ω, 8V to 28V supply, industrial temp -40°C to +85°C, 32-TQFN exposed pad package.

$6.18Ref. price · indicative, final on quote
Packaging32-WQFN Exposed Pad
RoHSROHS3 Compliant
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

MAX9736AETJ+ specifications
ParameterValue
TypeClass D
Output type1-Channel (Mono) or 2-Channel (Stereo)
MountingSurface Mount
Voltage8V ~ 28V
Max output power x channels @ load35W x 1 @ 4Ohm; 17.5W x 2 @ 8Ohm
Operating temperature-40°C ~ 85°C (TA)
PackageTube
FeaturesDepop, Mute, Short-Circuit and Thermal Protection, Shutdown
Case32-WQFN Exposed Pad

Product details

Class D amplifier for mono or stereo audio — 35W into 4Ω

Built-in depop, mute, short-circuit protection, and thermal shutdown reduce the external component count and improve system reliability. The output can be configured as a single mono channel or a stereo pair, letting one BOM line serve multiple product variants.

Active production — no end-of-life risk on this BOM line

If you need a reel variant, the MAX9736AETJ+T is the tape-and-reel version of the same die; the +T suffix is the only difference.

32-TQFN exposed pad — thermal and layout notes

The datasheet layout recommendation calls for a solid copper pour on the top layer, stitched with vias to the inner ground plane. Keep the output filter inductor and bypass capacitors close to the package to minimize radiated EMI from the switching output stage.

Frequently asked questions

What is the difference between MAX9736AETJ+ and MAX9736AETJ+T?

The only difference is the shipping medium: MAX9736AETJ+ comes in a tube, while MAX9736AETJ+T is the tape-and-reel version. The silicon, package, and electrical ratings are identical.

What is the maximum output power of MAX9736AETJ+?

35W into a 4Ω load with a single channel, or 17.5W per channel into 8Ω in stereo mode.

Does MAX9736AETJ+ require an external heatsink?

It depends on the output power and ambient temperature. The exposed pad on the 32-TQFN package is designed to be soldered to a PCB copper plane; for continuous 35W output at high ambient temperatures, additional heatsinking or forced airflow may be needed to stay within the thermal limits.
