Analog Devices MAX22702DAWA+
MPNMAX22702DAWA+
End of Life
DGTL ISO 5KV 1CH GATE DVR 8SOIC
$6.18Ref. price · indicative, final on quote
Packaging8-SOIC (0.295", 7.50mm Width)
RoHSROHS3 Compliant
Independent supplier — new & surplus stockAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Mounting | Surface Mount |
| Voltage - isolation | 5000Vrms |
| Voltage - output supply | 6V ~ 28V |
| Current - output high, low | 2.35A, 3.7A |
| Operating temperature | -40°C ~ 125°C |
| Pulse width distortion | 2ns |
| Approval agency | CSA, cUL, UL, VDE |
| Package | Tube |
| Technology | Capacitive Coupling |
| Case | 8-SOIC (0.295\", 7.50mm Width) |
| Channels | 1 |
| Rise (Fall time) | 3.6ns, 1.8ns (Max) |
| Propagation delay tpLH (tpHL) | 36ns, 36ns |
| Common mode transient immunity | 300kV/µs (Typ) |
