Analog Devices LTC6802IG-2#PBF — Analog & Data Acquisition

LTC6802IG-2#PBF Battery Monitor, 1-12 Cells, 44-SSOP

MPNLTC6802IG-2#PBF
End of Life

Analog Devices LTC6802IG-2#PBF, Lithium Ion Battery Monitor, 1 to 12 Cells, Over/Under Voltage Protection, Serial Interface, -40°C to 85°C, 44-SSOP, Tube.

$36.17Ref. price · indicative, final on quote
Packaging44-FSOP (0.209", 5.30mm Width)
RoHSROHS3 Compliant
Independent supplier — new & surplus stockAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

LTC6802IG-2#PBF specifications
ParameterValue
MountingSurface Mount
InterfaceSerial
Operating temperature-40°C ~ 85°C (TA)
PackageTube
FunctionBattery Monitor
Case44-FSOP (0.209\", 5.30mm Width)
Number of cells1 ~ 12
Fault protectionOver/Under Voltage
Battery chemistryLithium Ion

Product details

The Analog Devices LTC6802IG-2#PBF is a lithium-ion battery stack monitor that measures the voltage of 1 to 12 series-connected cells. It reports measurements over a serial interface and includes integrated over-voltage and under-voltage fault detection.

Supporting 1 to 12 cells covers common module sizes for lithium-ion packs. The over/under voltage fault protection is a hardware-level trip that can trigger an interrupt or drive a shutdown FET without waiting for the host microcontroller to poll.

Frequently asked questions

How many cells does LTC6802IG-2#PBF support?

It monitors 1 to 12 series-connected lithium-ion cells.

Does LTC6802IG-2#PBF have under-voltage protection?

Yes, the device includes both over-voltage and under-voltage fault detection.

What is the difference between LTC6802-1 and LTC6802-2?

The LTC6802-1 uses a serial interface with a daisy-chainable SPI protocol, while the LTC6802-2 uses a parallel interface for direct connection to a host microcontroller. The LTC6802IG-2#PBF is the serial-interface variant.
