ASVMB-11.0592MHZ-XY-T
Abracon LLC
ASVMB, Pure Silicon™Tape & Reel (TR); Cut Tape (CT)-40°C~105°C
Ref. price$2.5028
Lead time on requestGet quote
ASVM Pure Silicon MEMS Clock Oscillators
331 variants · Abracon LLC
About the ASVM Pure Silicon MEMS Clock Oscillators
The Abracon LLC ASVM Pure Silicon MEMS Clock Oscillators series groups 331 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common absolute pull range of -, base resonator of MEMS and height - seated of 0.035\" (0.90mm). Variants differ by case, current - supply and current - supply (Disable), so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 4-SMD, No Lead Exposed Pad · 6-SMD, No Lead Exposed Pad
- Current - supply
- 16mA · 35mA
- Current - supply (Disable)
- 15µA · 22mA
- Frequency
- 11.0592 MHz · 18.432 MHz · 20 MHz · 32 MHz · 66.666 MHz · 76.8 MHz · 80 MHz · 106.25 MHz
- Frequency stability
- - · ±10ppm
- Function
- Enable/Disable · Standby (Power Down)
- Operating temperature
- -55°C~125°C · -40°C~85°C · -40°C~105°C
- Output
- CMOS · LVCMOS
Shared specifications
- Absolute pull range
- -
- Base resonator
- MEMS
- Height - seated
- 0.035\" (0.90mm)
- Mounting
- Surface Mount
- Ratings
- -
- Size (Dimension)
- 0.276\" L x 0.197\" W (7.00mm x 5.00mm)
- Spread spectrum bandwidth
- -
- Type
- XO (Standard)
Variant comparison
| Parameter | ASVMB-11.0592MHZ-XY-T | ASVMB-20.000MHZ-XY-T | ASVMB-11.0592MHZ-LY-T | ASVMB-20.000MHZ-LY-T | ASVMB-80.000MHZ-LY-T | ASVMPC-32.000MHZ-Z-T |
|---|---|---|---|---|---|---|
| Case | 4-SMD, No Lead Exposed Pad | 4-SMD, No Lead Exposed Pad | 4-SMD, No Lead Exposed Pad | 4-SMD, No Lead Exposed Pad | 4-SMD, No Lead Exposed Pad | 6-SMD, No Lead Exposed Pad |
| Current - supply | 16mA | 16mA | 16mA | 16mA | 16mA | 35mA |
| Current - supply (Disable) | 15µA | 15µA | 15µA | 15µA | 15µA | 22mA |
| Frequency | 11.0592 MHz | 20 MHz | 11.0592 MHz | 20 MHz | 80 MHz | 32 MHz |
| Frequency stability | ±10ppm | ±10ppm | ±10ppm | ±10ppm | ±10ppm | - |
| Function | Standby (Power Down) | Standby (Power Down) | Standby (Power Down) | Standby (Power Down) | Standby (Power Down) | Enable/Disable |
| Operating temperature | -40°C~105°C | -40°C~105°C | -40°C~85°C | -40°C~85°C | -40°C~85°C | -55°C~125°C |
| Output | LVCMOS | LVCMOS | LVCMOS | LVCMOS | LVCMOS | CMOS |
Request a quote on any ASVM Pure Silicon MEMS Clock Oscillators part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
