STMicroelectronics STD5 Series

7 variants · STMicroelectronics

About the STMicroelectronics STMicroelectronics STD5 Series series

The STMicroelectronics STMicroelectronics STD5 Series series groups 7 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common drive voltage (Max rds on, min rds on) of 10V, FET feature of - and FET type of N-Channel. Variants differ by case, current - continuous drain (Id) @ 25°C and drain to source voltage, so you can match the exact case your application requires using the selection guide below. All listed STMicroelectronics STD5 Series part numbers are active and orderable.

Select a variant by

Case: TO-251-3 Short Leads, IPak, TO-251AA · TO-252-3, DPak (2 Leads + Tab), SC-63
Current - continuous drain (Id) @ 25°C: 3A (Tc) · 3.5A (Tc) · 4A (Tc) · 4.2A (Tc) · 4.4A (Tc)
Drain to source voltage: 400 V · 525 V · 600 V · 620 V · 800 V · 950 V
Gate charge (Qg) (Max) @ vgs: 5 nC @ 10 V · 8.5 nC @ 10 V · 8.6 nC @ 10 V · 12.5 nC @ 10 V · 16.9 nC @ 10 V · 17 nC @ 10 V · 26 nC @ 10 V
Input capacitance (Ciss) (Max) @ vds: 177 pF @ 100 V · 211 pF @ 100 V · 220 pF @ 100 V · 305 pF @ 25 V · 375 pF @ 100 V · 529 pF @ 25 V · 680 pF @ 50 V
Mounting type: Surface Mount · Through Hole
Operating temperature: -55°C ~ 150°C (TJ) · 150°C (TJ)
Package: Tape & Reel (TR) Cut Tape (CT) · Tube

Variant comparison

Parameter	STD5N60DM2	STD5N60M2	STD5N62K3	STD5N80K5	STD5N95K5	STD5NK40Z-1
Case	TO-252-3, DPak (2 Leads + Tab), SC-63	TO-252-3, DPak (2 Leads + Tab), SC-63	TO-252-3, DPak (2 Leads + Tab), SC-63	TO-252-3, DPak (2 Leads + Tab), SC-63	TO-252-3, DPak (2 Leads + Tab), SC-63	TO-251-3 Short Leads, IPak, TO-251AA
Current - continuous drain (Id) @ 25°C	3.5A (Tc)	3.5A (Tc)	4.2A (Tc)	4A (Tc)	3.5A (Tc)	3A (Tc)
Drain to source voltage	600 V	600 V	620 V	800 V	950 V	400 V
Gate charge (Qg) (Max) @ vgs	8.6 nC @ 10 V	8.5 nC @ 10 V	26 nC @ 10 V	5 nC @ 10 V	12.5 nC @ 10 V	17 nC @ 10 V
Input capacitance (Ciss) (Max) @ vds	375 pF @ 100 V	211 pF @ 100 V	680 pF @ 50 V	177 pF @ 100 V	220 pF @ 100 V	305 pF @ 25 V
Mounting type	Surface Mount	Surface Mount	Surface Mount	Surface Mount	Surface Mount	Through Hole
Operating temperature	-55°C ~ 150°C (TJ)	150°C (TJ)	-55°C ~ 150°C (TJ)	-55°C ~ 150°C (TJ)	-55°C ~ 150°C (TJ)	-55°C ~ 150°C (TJ)
Package	Tape & Reel (TR) Cut Tape (CT)	Tape & Reel (TR) Cut Tape (CT)	Tape & Reel (TR) Cut Tape (CT)	Tape & Reel (TR) Cut Tape (CT)	Tape & Reel (TR) Cut Tape (CT)	Tube

Shared specifications

Drive voltage (Max rds on, min rds on): 10V
FET feature: -
FET type: N-Channel
Technology: MOSFET (Metal Oxide)

Request a quote on any STMicroelectronics STD5 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.

Frequently asked questions

How do the STMicroelectronics STMicroelectronics STD5 Series variants differ?: STMicroelectronics STD5 Series part numbers differ by case, current - continuous drain (Id) @ 25°C, drain to source voltage and gate charge (Qg) (Max) @ vgs. Use the selection guide above to pick by case.
How many STMicroelectronics STMicroelectronics STD5 Series part numbers are listed?: 7 STMicroelectronics STMicroelectronics STD5 Series part numbers are listed, each with specifications and a datasheet where available.
How do I get pricing and lead time for STMicroelectronics STMicroelectronics STD5 Series?: Request a quote (RFQ) for any STMicroelectronics STD5 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
