AT25PE80-SSHN-T
Renesas Electronics Corporation
1.7V ~ 3.6VTape & Reel (TR) Cut Tape (CT)-40°C ~ 85°C (TC)
Ref. price$1.8600
Lead time on requestGet quote ›
Renesas Electronics AT25 Series
61 variants · Renesas Electronics
About the Renesas Electronics Renesas Electronics AT25 Series series
The Renesas Electronics Renesas Electronics AT25 Series series groups 61 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common memory format of FLASH, memory interface of SPI and memory type of Non-Volatile. Variants differ by case, frequency and memory organization, so you can match the exact case your application requires using the selection guide below. The range mixes active and legacy part numbers, so you can source both current Renesas Electronics AT25 Series variants and discontinued ones from a single page.
Select a variant by
- Case
- 8-SOIC (0.154\", 3.90mm Width) · 8-SOIC (0.209\", 5.30mm Width) · 8-TSSOP (0.173\", 4.40mm Width) · 8-UDFN Exposed Pad · 8-UFDFN Exposed Pad · 8-XFBGA, WLCSP
- Frequency
- 85 MHz · 100 MHz · 104 MHz
- Memory organization
- 128K x 8 · 256 Bytes x 4096 pages · 256 Bytes x 16384 pages · 256K x 8 · 512K x 8
- Memory size
- 1Mbit · 2Mbit · 4Mbit · 8Mbit · 32Mbit
- Operating temperature
- -40°C ~ 85°C (TC) · -40°C ~ 125°C (TC)
- Package
- Tape & Reel (TR) Cut Tape (CT) · Tray · Tube
- Voltage
- 1.65V ~ 3.6V · 1.7V ~ 3.6V · 2.7V ~ 3.6V
- Write cycle time - word, page
- 7µs, 3ms · 8µs, 2.5ms · 8µs, 3.5ms · 12µs, 5ms
Variant comparison
| Parameter | AT25DF011-XMHN-T | AT25DF021A-MAHNHR-T | AT25DF021A-SSHN-T | AT25DF021A-XMHNHR-T | AT25DF041B-MAHNHR-T | AT25DF041B-MHN-T |
|---|---|---|---|---|---|---|
| Case | 8-TSSOP (0.173\", 4.40mm Width) | 8-UFDFN Exposed Pad | 8-SOIC (0.154\", 3.90mm Width) | 8-TSSOP (0.173\", 4.40mm Width) | 8-UFDFN Exposed Pad | 8-UDFN Exposed Pad |
| Frequency | 104 MHz | 85 MHz | 104 MHz | 85 MHz | 85 MHz | 104 MHz |
| Memory organization | 128K x 8 | 256K x 8 | 256K x 8 | 256K x 8 | 512K x 8 | 512K x 8 |
| Memory size | 1Mbit | 2Mbit | 2Mbit | 2Mbit | 4Mbit | 4Mbit |
| Operating temperature | -40°C ~ 85°C (TC) | -40°C ~ 125°C (TC) | -40°C ~ 85°C (TC) | -40°C ~ 125°C (TC) | -40°C ~ 125°C (TC) | -40°C ~ 85°C (TC) |
| Package | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) |
| Voltage | 1.65V ~ 3.6V | 1.7V ~ 3.6V | 1.65V ~ 3.6V | 1.7V ~ 3.6V | 1.7V ~ 3.6V | 1.65V ~ 3.6V |
| Write cycle time - word, page | 8µs, 3.5ms | 12µs, 5ms | 8µs, 2.5ms | 12µs, 5ms | 8µs, 2.5ms | 8µs, 2.5ms |
Shared specifications
- Memory format
- FLASH
- Memory interface
- SPI
- Memory type
- Non-Volatile
- Mounting type
- Surface Mount
- Technology
- FLASH
Request a quote on any Renesas Electronics AT25 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Renesas Electronics Renesas Electronics AT25 Series variants differ?
- Renesas Electronics AT25 Series part numbers differ by case, frequency, memory organization and memory size. Use the selection guide above to pick by case.
- How many Renesas Electronics Renesas Electronics AT25 Series part numbers are listed?
- 61 Renesas Electronics Renesas Electronics AT25 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Renesas Electronics Renesas Electronics AT25 Series?
- Request a quote (RFQ) for any Renesas Electronics AT25 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
