TOP252GN-TL
Power Integrations
Tape & Reel (TR); Cut Tape (CT)66kHz15 W
Ref. price$1.1700
Lead time on requestGet quote ›
Power Integrations TOP25 Series
26 variants · Power Integrations
About the Power Integrations Power Integrations TOP25 Series series
The Power Integrations Power Integrations TOP25 Series series groups 26 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common control features of -, duty cycle of 78% and fault protection of Current Limiting, Over Temperature, Over Voltage. Variants differ by case, frequency and mounting type, so you can match the exact case your application requires using the selection guide below. All listed Power Integrations TOP25 Series part numbers are active and orderable.
Select a variant by
- Case
- 7-SSIP, 6 Leads, Exposed Pad, Formed Leads · 8-DIP (0.300\", 7.62mm), 7 Leads · 8-SMD (7 Leads), Gull Wing · TO-220-7 Formed Leads, 6 Leads
- Frequency
- 66kHz · 66kHz, 132kHz
- Mounting type
- Surface Mount · Through Hole
- Package
- Tape & Reel (TR); Cut Tape (CT) · Tube
- Power (Watts)
- 15 W · 25 W · 28 W · 30 W · 62 W · 81 W
Variant comparison
| Parameter | TOP252GN-TL | TOP252PN | TOP253EN | TOP253GN-TL | TOP253PN | TOP254EN |
|---|---|---|---|---|---|---|
| Case | 8-SMD (7 Leads), Gull Wing | 8-DIP (0.300\", 7.62mm), 7 Leads | 7-SSIP, 6 Leads, Exposed Pad, Formed Leads | 8-SMD (7 Leads), Gull Wing | 8-DIP (0.300\", 7.62mm), 7 Leads | 7-SSIP, 6 Leads, Exposed Pad, Formed Leads |
| Frequency | 66kHz | 66kHz | 66kHz, 132kHz | 66kHz | 66kHz | 66kHz, 132kHz |
| Mounting type | Surface Mount | Through Hole | Through Hole | Surface Mount | Through Hole | Through Hole |
| Package | Tape & Reel (TR); Cut Tape (CT) | Tube | Tube | Tape & Reel (TR); Cut Tape (CT) | Tube | Tube |
| Power (Watts) | 15 W | 15 W | 25 W | 25 W | 25 W | 62 W |
Shared specifications
- Control features
- -
- Duty cycle
- 78%
- Fault protection
- Current Limiting, Over Temperature, Over Voltage
- Internal switch
- Yes
- Operating temperature
- -40°C~150°C(TJ)
- Output isolation
- Isolated
- Topology
- Flyback
- Voltage - breakdown
- 700V
- Voltage - supply (Vcc (Vdd))
- -
