HCPL0453R2
onsemi
Tape & Reel (TR) Cut Tape (CT)-40°C ~ 85°CDC
Ref. price$2.8600
Lead time on requestGet quote ›
onsemi HCPL Series
31 variants · onsemi
About the onsemi onsemi HCPL Series series
The onsemi onsemi HCPL Series series groups 31 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common case of 8-SOIC (0.154\", 3.90mm Width), input type of DC and mounting type of Surface Mount. Variants differ by current - DC forward (If), current - output (Channel) and number of channels, so you can match the exact current - DC forward (If) your application requires using the selection guide below.
Select a variant by
- Current - DC forward (If)
- 25 mA · 50mA
- Current - output (Channel)
- 8mA · 15 mA · 50 mA
- Number of channels
- 1 · 2
- Operating temperature
- -40°C ~ 85°C · -40°C~85°C
- Output type
- Open Collector · Transistor · Transistor with Base
- Package
- Box · Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT) · Tube
- Rise (Fall time)
- - · 16ns, 4ns · 50ns, 12ns
- Voltage - forward (Vf)
- 1.45V · 1.75V (Max)
Variant comparison
| Parameter | HCPL0453R2 | HCPL0500R2 | HCPL0500V | HCPL0501 | HCPL0531 | HCPL0531R2 |
|---|---|---|---|---|---|---|
| Current - DC forward (If) | 25 mA | 25 mA | 25 mA | 25 mA | 25 mA | 25 mA |
| Current - output (Channel) | 8mA | 8mA | 8mA | 8mA | 8mA | 8mA |
| Number of channels | 1 | 1 | 1 | 1 | 2 | 2 |
| Operating temperature | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C~85°C | -40°C~85°C | -40°C ~ 85°C |
| Output type | Transistor | Transistor with Base | Transistor with Base | Transistor with Base | Transistor | Transistor |
| Package | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tube | Box | Tube | Tape & Reel (TR) Cut Tape (CT) |
| Rise (Fall time) | - | - | - | - | - | - |
| Voltage - forward (Vf) | 1.45V | 1.45V | 1.45V | 1.45V | 1.45V | 1.45V |
Shared specifications
- Case
- 8-SOIC (0.154\", 3.90mm Width)
- Input type
- DC
- Mounting type
- Surface Mount
Request a quote on any onsemi HCPL Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the onsemi onsemi HCPL Series variants differ?
- onsemi HCPL Series part numbers differ by current - DC forward (If), current - output (Channel), number of channels and operating temperature. Use the selection guide above to pick by current - DC forward (If).
- How many onsemi onsemi HCPL Series part numbers are listed?
- 31 onsemi onsemi HCPL Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for onsemi onsemi HCPL Series?
- Request a quote (RFQ) for any onsemi HCPL Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
