onsemi FDMS Series

46 variants · onsemi

About the onsemi onsemi FDMS Series series

The onsemi onsemi FDMS Series series groups 46 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common FET feature of -, FET type of N-Channel and mounting type of Surface Mount. Variants differ by case, current - continuous drain (Id) @ 25°C and drain to source voltage, so you can match the exact case your application requires using the selection guide below. The range mixes active and legacy part numbers, so you can source both current onsemi FDMS Series variants and discontinued ones from a single page.

Select a variant by

Case
8-PowerTDFN · 8-PowerWDFN
Current - continuous drain (Id) @ 25°C
2.8A (Ta), 14A (Tc) · 3.7A (Ta), 20A (Tc) · 14A (Ta), 84A (Tc) · 17A (Tc) · 19A (Ta), 22A (Tc) · 21A (Ta), 49A (Tc) · 22A (Ta), 147A (Tc) · 24A (Ta), 49A (Tc) · 26A (Ta), 49A (Tc) · 31A (Ta), 49A (Tc) · 31.3A (Ta), 100A (Tc) · 100A (Tc)
Drain to source voltage
30 V · 40 V · 75 V · 80 V · 100 V · 200 V · 250 V
Drive voltage (Max rds on, min rds on)
4.5V, 10V · 6V, 10V · 10V
Gate charge (Qg) (Max) @ vgs
37 nC @ 10 V · 42 nC @ 10 V · 46 nC @ 10 V · 47 nC @ 10 V · 57 nC @ 10 V · 65 nC @ 10 V · 73 nC @ 10 V · 100 nC @ 10 V · 118 nC @ 10 V · 133 nC @ 10 V
Input capacitance (Ciss) (Max) @ vds
2280 pF @ 15 V · 2315 pF @ 100 V · 2365 pF @ 100 V · 3000 pF @ 15 V · 3100 pF @ 40 V · 3550 pF @ 15 V · 4500 pF @ 50 V · 5350 pF @ 40 V · 5915 pF @ 37.5 V · 8705 pF @ 15 V · 8725 pF @ 20 V
Operating temperature
-55°C ~ 150°C (TJ) · -55°C~150°C(TJ)
Package
Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT)

Variant comparison

ParameterFDMS003N08CFDMS007N08LCFDMS015N04BFDMS0300SFDMS0306ASFDMS0308AS
Case8-PowerTDFN8-PowerTDFN8-PowerTDFN8-PowerTDFN8-PowerTDFN8-PowerTDFN
Current - continuous drain (Id) @ 25°C22A (Ta), 147A (Tc)14A (Ta), 84A (Tc)31.3A (Ta), 100A (Tc)31A (Ta), 49A (Tc)26A (Ta), 49A (Tc)24A (Ta), 49A (Tc)
Drain to source voltage80 V80 V40 V30 V30 V30 V
Drive voltage (Max rds on, min rds on)6V, 10V4.5V, 10V10V4.5V, 10V4.5V, 10V4.5V, 10V
Gate charge (Qg) (Max) @ vgs73 nC @ 10 V46 nC @ 10 V118 nC @ 10 V133 nC @ 10 V57 nC @ 10 V47 nC @ 10 V
Input capacitance (Ciss) (Max) @ vds5350 pF @ 40 V3100 pF @ 40 V8725 pF @ 20 V8705 pF @ 15 V3550 pF @ 15 V3000 pF @ 15 V
Operating temperature-55°C ~ 150°C (TJ)-55°C ~ 150°C (TJ)-55°C ~ 150°C (TJ)-55°C ~ 150°C (TJ)-55°C ~ 150°C (TJ)-55°C ~ 150°C (TJ)
PackageTape & Reel (TR) Cut Tape (CT)Tape & Reel (TR) Cut Tape (CT)Tape & Reel (TR) Cut Tape (CT)Tape & Reel (TR) Cut Tape (CT)Tape & Reel (TR) Cut Tape (CT)Tape & Reel (TR) Cut Tape (CT)

Shared specifications

FET feature
-
FET type
N-Channel
Mounting type
Surface Mount
Technology
MOSFET (Metal Oxide)
Vgs
±20V

Request a quote on any onsemi FDMS Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.

Frequently asked questions

How do the onsemi onsemi FDMS Series variants differ?
onsemi FDMS Series part numbers differ by case, current - continuous drain (Id) @ 25°C, drain to source voltage and drive voltage (Max rds on, min rds on). Use the selection guide above to pick by case.
How many onsemi onsemi FDMS Series part numbers are listed?
46 onsemi onsemi FDMS Series part numbers are listed, each with specifications and a datasheet where available.
How do I get pricing and lead time for onsemi onsemi FDMS Series?
Request a quote (RFQ) for any onsemi FDMS Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
