MKL26Z128VLH4
NXP USA Inc.
Surface MountTrayBrown-out Detect/Reset, DMA, I²S, LVD, POR, PWM, WDT
Ref. price$7.1600
Lead time on requestGet quote
NXP USA Inc. MKL2 Series
60 variants · NXP USA Inc.
About the NXP USA Inc. MKL2 Series
The NXP USA Inc. MKL2 Series series groups 60 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common core processor of ARM® Cortex®-M0+, core size of 32-Bit Single-Core and oscillator type of Internal. Variants differ by case, connectivity and data converters, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 32-UFQFN Exposed Pad · 32-VFQFN Exposed Pad · 48-UFQFN Exposed Pad · 48-VFQFN Exposed Pad · 64-LFBGA · 64-LQFP · 80-LQFP · 100-LQFP · 121-LFBGA
- Connectivity
- I2C, LINbus, SPI, UART/USART, USB, USB OTG · I²C, FlexIO, SPI, UART/USART, USB · I²C, LINbus, SPI, UART/USART, USB, USB OTG · I²C, SPI, UART/USART, USB
- Data converters
- A/D - 16bit; D/A - 12bit · A/D 8x16b · A/D 13x16b; D/A 1x12b · A/D 14x12b · A/D 14x16b; D/A 1x12b · A/D 16x16b; D/A 1x12b
- Mounting
- Surface Mount · Surface Mount, Wettable Flank
- Number of i (O)
- 23 · 24 · 36 · 50 · 66 · 80 · 84
- Operating temperature
- -40°C ~ 105°C (TA) · -40°C~105°C(TA)
- Package
- Tape & Reel (TR) · Tray
- Peripherals
- Brown-out Detect/Reset, DMA, I²S, LVD, POR, PWM, WDT · Brown-out Detect/Reset, DMA, LVD, POR, PWM, WDT · DMA, I²S, LVD, POR, PWM, WDT · DMA, I²S, PWM, WDT
Shared specifications
- Core processor
- ARM® Cortex®-M0+
- Core size
- 32-Bit Single-Core
- Oscillator type
- Internal
- Program memory type
- FLASH
- Speed
- 48MHz
- Voltage - supply (Vcc (Vdd))
- 1.71V ~ 3.6V
Variant comparison
| Parameter | MKL25Z32VFT4 | MKL26Z128VLH4 | MKL26Z256VMP4 | MKL27Z256VFT4 | MKL27Z64VFM4 | MKL26Z64VFM4 |
|---|---|---|---|---|---|---|
| Case | 48-VFQFN Exposed Pad | 64-LQFP | 64-LFBGA | 48-UFQFN Exposed Pad | 32-UFQFN Exposed Pad | 32-VFQFN Exposed Pad |
| Connectivity | I²C, LINbus, SPI, UART/USART, USB, USB OTG | I²C, LINbus, SPI, UART/USART, USB, USB OTG | I²C, LINbus, SPI, UART/USART, USB, USB OTG | I²C, SPI, UART/USART, USB | I²C, FlexIO, SPI, UART/USART, USB | I²C, LINbus, SPI, UART/USART, USB, USB OTG |
| Data converters | A/D 13x16b; D/A 1x12b | A/D - 16bit; D/A - 12bit | A/D - 16bit; D/A - 12bit | A/D 16x16b; D/A 1x12b | A/D 8x16b | A/D - 16bit; D/A - 12bit |
| Mounting | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount, Wettable Flank |
| Number of i (O) | 36 | 50 | 50 | 36 | 24 | 23 |
| Operating temperature | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) |
| Package | Tray | Tray | Tray | Tray | Tray | Tray |
| Peripherals | Brown-out Detect/Reset, DMA, LVD, POR, PWM, WDT | Brown-out Detect/Reset, DMA, I²S, LVD, POR, PWM, WDT | Brown-out Detect/Reset, DMA, I²S, LVD, POR, PWM, WDT | DMA, I²S, LVD, POR, PWM, WDT | DMA, I²S, PWM, WDT | Brown-out Detect/Reset, DMA, I²S, LVD, POR, PWM, WDT |
Request a quote on any NXP USA Inc. MKL2 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
