PMEG030V030EPDZ
Nexperia USA Inc.
Tape & Reel (TR) Cut Tape (CT)Fast Recovery =< 500ns, > 200mA (Io)AEC-Q101
Ref. price$0.5500
Lead time on requestGet quote ›
Nexperia USA Inc. PMEG Series
120 variants · Nexperia USA Inc.
About the Nexperia USA Inc. Nexperia USA Inc. PMEG Series series
The Nexperia USA Inc. Nexperia USA Inc. PMEG Series series groups 120 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common mounting type of Surface Mount, package of Tape & Reel (TR) Cut Tape (CT) and speed of Fast Recovery =< 500ns, > 200mA (Io). Variants differ by case, current - reverse leakage @ vr and operating temperature - junction, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- SOD-128 · TO-277, 3-PowerDFN
- Current - reverse leakage @ vr
- 1.2 µA @ 60 V · 2.5 µA @ 100 V · 44 µA @ 45 V · 80 µA @ 45 V · 98 µA @ 45 V · 100 µA @ 45 V · 100 µA @ 50 V · 150 µA @ 30 V · 300 nA @ 100 V · 450 nA @ 100 V
- Operating temperature - junction
- 175°C · 175°C (Max)
- Reverse recovery time
- 5 ns · 8 ns · 12 ns · 20 ns · 24 ns · 40 ns · 49 ns · 60 ns
- Voltage - DC reverse (Vr)
- 30 V · 45 V · 50 V · 60 V · 100 V
- Voltage - forward (Vf) (Max) @ if
- 420 mV @ 3 A · 450 mV @ 3 A · 510 mV @ 15 A · 545 mV @ 10 A · 550 mV @ 15 A · 620 mV @ 2 A · 710 mV @ 3 A · 770 mV @ 2 A · 770 mV @ 3 A · 810 mV @ 5 A
- Capacitance @ vr, f
- 135pF @ 1V, 1MHz · 200pF @ 1V, 1MHz · 410pF @ 1V, 1MHz · 495pF @ 1V, 1MHz · 600pF @ 10V, 1MHz · 800pF @ 10V, 1MHz · 830pF @ 1V, 1MHz · 1700pF @ 1V, 1MHz
- Current - average rectified
- 2A · 3A · 5A · 10A · 15A
Variant comparison
| Parameter | PMEG030V030EPDZ | PMEG045T030EPDZ | PMEG045T100EPEZ | PMEG045T150EIPDZ | PMEG045T150EPDZ | PMEG050T150EPDZ |
|---|---|---|---|---|---|---|
| Case | TO-277, 3-PowerDFN | TO-277, 3-PowerDFN | TO-277, 3-PowerDFN | TO-277, 3-PowerDFN | TO-277, 3-PowerDFN | TO-277, 3-PowerDFN |
| Current - reverse leakage @ vr | 150 µA @ 30 V | 44 µA @ 45 V | 80 µA @ 45 V | 98 µA @ 45 V | 100 µA @ 45 V | 100 µA @ 50 V |
| Operating temperature - junction | 175°C (Max) | 175°C (Max) | 175°C (Max) | 175°C (Max) | 175°C (Max) | 175°C (Max) |
| Reverse recovery time | 12 ns | 24 ns | 40 ns | 49 ns | 20 ns | 60 ns |
| Voltage - DC reverse (Vr) | 30 V | 45 V | 45 V | 45 V | 45 V | 50 V |
| Voltage - forward (Vf) (Max) @ if | 450 mV @ 3 A | 420 mV @ 3 A | 545 mV @ 10 A | 510 mV @ 15 A | 550 mV @ 15 A | 550 mV @ 15 A |
| Capacitance @ vr, f | 495pF @ 1V, 1MHz | 830pF @ 1V, 1MHz | 600pF @ 10V, 1MHz | 1700pF @ 1V, 1MHz | 800pF @ 10V, 1MHz | 800pF @ 10V, 1MHz |
| Current - average rectified | 3A | 3A | 10A | 15A | 15A | 15A |
Shared specifications
- Mounting type
- Surface Mount
- Package
- Tape & Reel (TR) Cut Tape (CT)
- Speed
- Fast Recovery =< 500ns, > 200mA (Io)
- Technology
- Schottky
Request a quote on any Nexperia USA Inc. PMEG Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
