BC807,215
Nexperia USA Inc.
Tape & Reel (TR) Cut Tape (CT)150°C (TJ)AEC-Q101
Ref. price$0.1700
Lead time on requestGet quote ›
Nexperia USA Inc. BC807 Series
28 variants · Nexperia USA Inc.
About the Nexperia USA Inc. Nexperia USA Inc. BC807 Series series
The Nexperia USA Inc. Nexperia USA Inc. BC807 Series series groups 28 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common current - collector (Ic) of 500 mA, current - collector cutoff of 100nA (ICBO) and frequency of 80MHz. Variants differ by case, DC current gain (hFE) (Min) @ ic, vce and mounting type, so you can match the exact case your application requires using the selection guide below. All listed Nexperia USA Inc. BC807 Series part numbers are active and orderable.
Select a variant by
- Case
- 3-XDFN Exposed Pad · SC-70, SOT-323 · TO-236-3, SC-59, SOT-23-3
- DC current gain (hFE) (Min) @ ic, vce
- 100 @ 100mA, 1V · 160 @ 100mA, 1V
- Mounting type
- Surface Mount · Surface Mount, Wettable Flank
- Operating temperature
- -55°C ~ 175°C (TA) · 150°C (TJ) · 150°C(TJ)
- Package
- Tape & Reel (TR) · Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT)
- Power - max
- 200 mW · 250 mW · 320 mW · 350 mW · 380 mW
Variant comparison
| Parameter | BC807-16,235 | BC807-16HR | BC807-16LVL | BC807-16QBZ | BC807-16QCZ | BC807-16W,115 |
|---|---|---|---|---|---|---|
| Case | TO-236-3, SC-59, SOT-23-3 | TO-236-3, SC-59, SOT-23-3 | TO-236-3, SC-59, SOT-23-3 | 3-XDFN Exposed Pad | 3-XDFN Exposed Pad | SC-70, SOT-323 |
| DC current gain (hFE) (Min) @ ic, vce | 100 @ 100mA, 1V | 100 @ 100mA, 1V | 100 @ 100mA, 1V | 100 @ 100mA, 1V | 100 @ 100mA, 1V | 100 @ 100mA, 1V |
| Mounting type | Surface Mount | Surface Mount | Surface Mount | Surface Mount, Wettable Flank | Surface Mount, Wettable Flank | Surface Mount |
| Operating temperature | 150°C(TJ) | -55°C ~ 175°C (TA) | 150°C (TJ) | 150°C (TJ) | 150°C (TJ) | 150°C(TJ) |
| Package | Tape & Reel (TR) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) |
| Power - max | 250 mW | 320 mW | 250 mW | 350 mW | 380 mW | 200 mW |
Shared specifications
- Current - collector (Ic)
- 500 mA
- Current - collector cutoff
- 100nA (ICBO)
- Frequency
- 80MHz
- Vce saturation (Max) @ ib, ic
- 700mV @ 50mA, 500mA
- Voltage - collector emitter breakdown
- 45 V
Request a quote on any Nexperia USA Inc. BC807 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Nexperia USA Inc. Nexperia USA Inc. BC807 Series variants differ?
- Nexperia USA Inc. BC807 Series part numbers differ by case, DC current gain (hFE) (Min) @ ic, vce, mounting type and operating temperature. Use the selection guide above to pick by case.
- How many Nexperia USA Inc. Nexperia USA Inc. BC807 Series part numbers are listed?
- 28 Nexperia USA Inc. Nexperia USA Inc. BC807 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Nexperia USA Inc. Nexperia USA Inc. BC807 Series?
- Request a quote (RFQ) for any Nexperia USA Inc. BC807 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
