Nexperia USA Inc. 74HC Series

182 variants · Nexperia USA Inc.

About the Nexperia USA Inc. Nexperia USA Inc. 74HC Series series

The Nexperia USA Inc. Nexperia USA Inc. 74HC Series series groups 182 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common current - output high, low of 5.2mA, 5.2mA, features of - and input logic level - high of 1.5V ~ 4.2V. Variants differ by case, current - quiescent and logic type, so you can match the exact case your application requires using the selection guide below.

Select a variant by

Case: 14-SOIC (0.154\", 3.90mm Width) · 14-TSSOP (0.173\", 4.40mm Width) · 14-VFQFN Exposed Pad
Current - quiescent: 2 µA · 40 µA
Logic type: Inverter · NAND Gate · NOR Gate
Max propagation delay @ v, max CL: 7ns @ 6V, 50pF · 14ns @ 6V, 50pF · 15ns @ 6V, 50pF
Number of circuits: 4 · 6
Number of inputs: 1 · 2
Operating temperature: -40°C ~ 125°C · -40°C~125°C
Package: Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT)

Variant comparison

Parameter	74HC00BQ,115	74HC00BQ-Q100,115	74HC00D,653	74HC00D-Q100,118	74HC00PW-Q100,118	74HC02BQ,115
Case	14-VFQFN Exposed Pad	14-VFQFN Exposed Pad	14-SOIC (0.154\", 3.90mm Width)	14-SOIC (0.154\", 3.90mm Width)	14-TSSOP (0.173\", 4.40mm Width)	14-VFQFN Exposed Pad
Current - quiescent	40 µA	40 µA	40 µA	40 µA	40 µA	2 µA
Logic type	NAND Gate	NAND Gate	NAND Gate	NAND Gate	NAND Gate	NOR Gate
Max propagation delay @ v, max CL	7ns @ 6V, 50pF	7ns @ 6V, 50pF	7ns @ 6V, 50pF	7ns @ 6V, 50pF	7ns @ 6V, 50pF	15ns @ 6V, 50pF
Number of circuits	4	4	4	4	4	4
Number of inputs	2	2	2	2	2	2
Operating temperature	-40°C ~ 125°C	-40°C ~ 125°C	-40°C ~ 125°C	-40°C~125°C	-40°C ~ 125°C	-40°C ~ 125°C
Package	Tape & Reel (TR) Cut Tape (CT)	Tape & Reel (TR) Cut Tape (CT)	Tape & Reel (TR) Cut Tape (CT)	Tape & Reel (TR); Cut Tape (CT)	Tape & Reel (TR) Cut Tape (CT)	Tape & Reel (TR) Cut Tape (CT)

Shared specifications

Current - output high, low: 5.2mA, 5.2mA
Features: -
Input logic level - high: 1.5V ~ 4.2V
Input logic level - low: 0.5V ~ 1.8V
Mounting type: Surface Mount
Voltage: 2V ~ 6V

Request a quote on any Nexperia USA Inc. 74HC Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
