74HC125DB,118
Nexperia USA Inc.
74HCTape & Reel (TR) Cut Tape (CT)-40°C ~ 125°C (TA)
Ref. price$0.5100
Lead time on requestGet quote
Nexperia USA Inc. 74HC Interface Series
53 variants · Nexperia USA Inc.
About the Nexperia USA Inc. 74HC Interface Series
The Nexperia USA Inc. 74HC Interface Series series groups 53 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common mounting of Surface Mount. Variants differ by case, operating temperature and package, so you can match the exact case your application requires using the selection guide below. The range mixes active and legacy part numbers, so you can source both current Nexperia USA Inc. 74HC Interface Series variants and discontinued ones from a single page.
Select a variant by
- Case
- 14-SOIC (0.154\", 3.90mm Width) · 14-SSOP (0.209\", 5.30mm Width) · 14-TSSOP (0.173\", 4.40mm Width) · 16-TSSOP (0.173\", 4.40mm Width) · 16-VFQFN Exposed Pad · 20-SOIC (0.295\", 7.50mm Width) · 20-SSOP (0.209\", 5.30mm Width) · 20-TSSOP (0.173\", 4.40mm Width) · 20-VFQFN Exposed Pad
- Operating temperature
- -40°C ~ 125°C · -40°C ~ 125°C (TA) · -40°C~125°C(TA)
- Package
- Tape & Reel (TR) · Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT) · Tube
- Current - output high, low
- 4mA, 4mA · 7.8mA, 7.8mA
- Voltage
- 2V ~ 6V · 4.5V ~ 5.5V
- Logic type
- AND Gate · Buffer, Non-Inverting · Transceiver, Non-Inverting
- Number of bits per element
- 1 · 4 · 8
Shared specifications
- Mounting
- Surface Mount
Variant comparison
| Parameter | 74HC125DB,118 | 74HC125PW,118 | 74HC126PW,118 | 74HC173PW,118 | 74HC244D,652 | 74HC245BQ-Q100X |
|---|---|---|---|---|---|---|
| Case | 14-SSOP (0.209\", 5.30mm Width) | 14-TSSOP (0.173\", 4.40mm Width) | 14-TSSOP (0.173\", 4.40mm Width) | 16-TSSOP (0.173\", 4.40mm Width) | 20-SOIC (0.295\", 7.50mm Width) | 20-VFQFN Exposed Pad |
| Operating temperature | -40°C ~ 125°C (TA) | -40°C~125°C(TA) | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C~125°C(TA) | -40°C ~ 125°C (TA) |
| Package | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tube | Tape & Reel (TR) Cut Tape (CT) |
| Current - output high, low | 7.8mA, 7.8mA | 7.8mA, 7.8mA | 7.8mA, 7.8mA | 7.8mA, 7.8mA | 7.8mA, 7.8mA | 7.8mA, 7.8mA |
| Voltage | 2V ~ 6V | 2V ~ 6V | 2V ~ 6V | 2V ~ 6V | 2V ~ 6V | 2V ~ 6V |
| Logic type | Buffer, Non-Inverting | Buffer, Non-Inverting | Buffer, Non-Inverting | — | Buffer, Non-Inverting | Transceiver, Non-Inverting |
| Number of bits per element | 1 | 1 | 1 | 4 | 4 | 8 |
Request a quote on any Nexperia USA Inc. 74HC Interface Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
