LQH44PN2R2MJ0L
Murata Electronics
2.2 µHTape & Reel (TR)0.047\" (1.20mm)
Ref. price$0.1649
Lead time on requestGet quote
Murata Electronics LQH44PN Series
34 variants · Murata Electronics
About the Murata Electronics LQH44PN Series
The Murata Electronics LQH44PN Series series groups 34 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common case of 1616 (4040 Metric), material - core of Ferrite and mounting of Surface Mount. Variants differ by current - saturation, current rating and DC resistance, so you can match the exact current - saturation your application requires using the selection guide below. The range mixes active and legacy part numbers, so you can source both current Murata Electronics LQH44PN Series variants and discontinued ones from a single page.
Select a variant by
- Current - saturation
- 1.05A · 1.32A · 1.45A · 1.6mA · 1.7A · 2.3A · 330mA · 880mA · 900mA
- Current rating
- 1 A · 1.23 A · 1.25 A · 1.38 A · 1.7 A · 2 A · 280 mA · 740 mA · 900 mA
- DC resistance
- 3.15Ohm · 55mOhm · 73.2mOhm Max · 88.8mOhm Max · 96mOhm Max · 106mOhm Max · 150mOhm · 290mOhm · 460mOhm
- Frequency - self resonant
- 4MHz · 12MHz · 17MHz · 25MHz · 40MHz · 55MHz · 68MHz · 90MHz
- Height - seated
- 0.047\" (1.20mm) · 0.071\" (1.80mm)
- Inductance
- 1.5 µH · 2.2 µH · 3.3 µH · 4.7 µH · 10 µH · 22 µH · 33 µH · 220 µH
- Inductance frequency - test
- 1 MHz · 100 kHz
- Operating temperature
- -40°C ~ 85°C · -40°C ~ 125°C
Shared specifications
- Case
- 1616 (4040 Metric)
- Material - core
- Ferrite
- Mounting
- Surface Mount
- Q @ freq
- -
- Ratings
- -
- Shielding
- Shielded
- Size (Dimension)
- 0.157\" L x 0.157\" W (4.00mm x 4.00mm)
- Tolerance
- ±20%
- Type
- Drum Core, Wirewound
Variant comparison
| Parameter | LQH44PN2R2MJ0L | LQH44PN3R3MPRL | LQH44PN100MPRL | LQH44PN1R5MJ0L | LQH44PN220MPRL | LQH44PN221MPRL |
|---|---|---|---|---|---|---|
| Current - saturation | 1.32A | 2.3A | 1.45A | 1.6mA | 1.05A | 330mA |
| Current rating | 1.23 A | 2 A | 1.25 A | 1.38 A | 900 mA | 280 mA |
| DC resistance | 88.8mOhm Max | 55mOhm | 150mOhm | 73.2mOhm Max | 290mOhm | 3.15Ohm |
| Frequency - self resonant | 68MHz | 40MHz | 25MHz | 90MHz | 17MHz | 4MHz |
| Height - seated | 0.047\" (1.20mm) | 0.071\" (1.80mm) | 0.071\" (1.80mm) | 0.047\" (1.20mm) | 0.071\" (1.80mm) | 0.071\" (1.80mm) |
| Inductance | 2.2 µH | 3.3 µH | 10 µH | 1.5 µH | 22 µH | 220 µH |
| Inductance frequency - test | 100 kHz | 100 kHz | 100 kHz | 100 kHz | 100 kHz | 100 kHz |
| Operating temperature | -40°C ~ 85°C | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 85°C | -40°C ~ 125°C | -40°C ~ 125°C |
Request a quote on any Murata Electronics LQH44PN Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
