GeneSiC Semiconductor 1N11 Series

2 variants · GeneSiC Semiconductor

About the GeneSiC Semiconductor 1N11 Series

The GeneSiC Semiconductor 1N11 Series series groups 2 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common case of DO-203AB, DO-5, Stud, current - average rectified of 40A and current - reverse leakage @ vr of 10 µA @ 50 V. Variants differ by operating temperature - junction and voltage - DC reverse (Vr), so you can match the exact operating temperature - junction your application requires using the selection guide below. All listed GeneSiC Semiconductor 1N11 Series part numbers are active and orderable.

Select a variant by

Operating temperature - junction: -65°C ~ 190°C · -65°C ~ 200°C
Voltage - DC reverse (Vr): 100 V · 600 V

Shared specifications

Case: DO-203AB, DO-5, Stud
Current - average rectified: 40A
Current - reverse leakage @ vr: 10 µA @ 50 V
Diode type: Standard
Mounting: Chassis, Stud Mount
Package: Bulk
Speed: Standard Recovery >500ns, > 200mA (Io)
Voltage - forward (Vf) (Max) @ if: 1.1 V @ 40 A

Variant comparison

Parameter	1N1184A	1N1190A
Operating temperature - junction	-65°C ~ 200°C	-65°C ~ 190°C
Voltage - DC reverse (Vr)	100 V	600 V

Request a quote on any GeneSiC Semiconductor 1N11 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
