Fairchild Semiconductor — Logic ICs

Fairchild Semiconductor Logic ICs — 7 part numbers with specifications and datasheets. Filter by key specs and request a quote on ICBOMS.

Base Product Number: CD4013 · CD40174 · CD4017 · 7SZ02
Package / Case: 14-SOIC (0.209", 5.30mm Width) · 16-DIP (0.300", 7.62mm) · 16-SOIC (0.209", 5.30mm Width) · 5-TSSOP, SC-70-5, SOT-353
Supplier Device Package: 14-SOP · 16-PDIP · 16-SOP · SC-70-5
Voltage - Supply: 3V ~ 15V · 3 V ~ 15 V · 1.65V ~ 5.5V · 4V ~ 5.5V
Operating Temperature: -55°C ~ 125°C (TA) · -55°C~125°C(TA) · -40°C~85°C · -40°C ~ 85°C
Current - Output High, Low: 8.8mA, 8.8mA · 32mA, 32mA · -
Max Propagation Delay @ V, Max CL: 120ns @ 15V, 50pF · 90ns @ 15V, 50pF · 4.3ns @ 5V, 50pF
Number of Bits per Element: 1 · 6 · 5
