EPC EPC2 Discrete Semiconductors Series

4 variants · EPCAll Discrete Semiconductors →

About the EPC EPC2 Discrete Semiconductors Series

The EPC EPC2 Discrete Semiconductors Series series groups 4 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common case of Die, mounting of Surface Mount and operating temperature of -40°C ~ 150°C (TJ). Variants differ by current - continuous drain (Id) @ 25°C, drain to source voltage and FET type, so you can match the exact current - continuous drain (Id) @ 25°C your application requires using the selection guide below. All listed EPC EPC2 Discrete Semiconductors Series part numbers are active and orderable.

Select a variant by

Current - continuous drain (Id) @ 25°C: 1.7A (Ta) · 3.4A (Ta) · 9.5A, 38A · 90A (Ta)
Drain to source voltage: 15 V · 60V · 80 V · 100 V
FET type: 2 N-Channel (Half Bridge) · N-Channel
Gate charge (Qg) (Max) @ vgs: 0.12 nC @ 5 V · 1.1 nC @ 5 V · 2.7nC @ 5V, 12nC @ 5V · 19 nC @ 5 V
Input capacitance (Ciss) (Max) @ vds: 14 pF @ 50 V · 118 pF @ 7.5 V · 300pF @ 30V, 1200pF @ 30V · 1940 pF @ 40 V
Rds on (Max) @ id, vgs: 2.2mOhm @ 29A, 5V · 11.5mOhm @ 20A, 5V, 2.7mOhm @ 20A, 5V · 26mOhm @ 1.5A, 5V · 550mOhm @ 100mA, 5V
Vgs(th) (Max) @ id: 2.5V @ 1mA · 2.5V @ 3mA, 2.5V @ 12mA · 2.5V @ 13mA · 2.5V @ 80µA

Shared specifications

Case: Die
Mounting: Surface Mount
Operating temperature: -40°C ~ 150°C (TJ)
Package: Tape & Reel (TR); Cut Tape (CT)

Variant comparison

Parameter	EPC2037	EPC2101	EPC2206	EPC2216
Current - continuous drain (Id) @ 25°C	1.7A (Ta)	9.5A, 38A	90A (Ta)	3.4A (Ta)
Drain to source voltage	100 V	60V	80 V	15 V
FET type	N-Channel	2 N-Channel (Half Bridge)	N-Channel	N-Channel
Gate charge (Qg) (Max) @ vgs	0.12 nC @ 5 V	2.7nC @ 5V, 12nC @ 5V	19 nC @ 5 V	1.1 nC @ 5 V
Input capacitance (Ciss) (Max) @ vds	14 pF @ 50 V	300pF @ 30V, 1200pF @ 30V	1940 pF @ 40 V	118 pF @ 7.5 V
Rds on (Max) @ id, vgs	550mOhm @ 100mA, 5V	11.5mOhm @ 20A, 5V, 2.7mOhm @ 20A, 5V	2.2mOhm @ 29A, 5V	26mOhm @ 1.5A, 5V
Vgs(th) (Max) @ id	2.5V @ 80µA	2.5V @ 3mA, 2.5V @ 12mA	2.5V @ 13mA	2.5V @ 1mA

Request a quote on any EPC EPC2 Discrete Semiconductors Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
