DMP2003UPS-13
Diodes Incorporated
Tape & Reel (TR) Cut Tape (CT)-55°C ~ 150°C (TJ)P-Channel
Ref. price$1.2900
Lead time on requestGet quote ›
Diodes Incorporated DMP2 Series
29 variants · Diodes Incorporated
About the Diodes Incorporated Diodes Incorporated DMP2 Series series
The Diodes Incorporated Diodes Incorporated DMP2 Series series groups 29 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common drain to source voltage of 20 V, FET feature of - and FET type of P-Channel. Variants differ by case, current - continuous drain (Id) @ 25°C and drive voltage (Max rds on, min rds on), so you can match the exact case your application requires using the selection guide below. All listed Diodes Incorporated DMP2 Series part numbers are active and orderable.
Select a variant by
- Case
- 4-UFBGA, WLBGA · 6-PowerUDFN · 6-UDFN Exposed Pad · 6-UFDFN Exposed Pad · 8-PowerTDFN · 8-PowerVDFN · 8-SOIC (0.154\", 3.90mm Width) · SOT-23-6 Thin, TSOT-23-6 · SOT-523 · TO-236-3, SC-59, SOT-23-3
- Current - continuous drain (Id) @ 25°C
- 4.1A (Ta) · 4.3A (Ta) · 6A (Ta) · 6.5A (Ta) · 6.6A (Ta) · 7.6A (Ta) · 8.1A (Ta) · 9A (Ta) · 11.1A (Ta) · 12.7A (Ta), 42A (Tc) · 150A (Tc) · 430mA (Ta)
- Drive voltage (Max rds on, min rds on)
- 1.5V, 4.5V · 1.8V, 4.5V · 2.5V, 4.5V · 2.5V, 10V
- Input capacitance (Ciss) (Max) @ vds
- 175 pF @ 16 V · 218 pF @ 10 V · 634 pF @ 10 V · 1496 pF @ 15 V · 1808 pF @ 15 V · 1837 pF @ 15 V · 2200 pF @ 10 V · 2400 pF @ 10 V · 2760 pF @ 15 V · 3350 pF @ 10 V · 8352 pF @ 10 V
- Operating temperature
- -55°C ~ 150°C (TJ) · -55°C~150°C(TJ)
- Package
- Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT)
- Power dissipation
- 1W (Ta) · 1.2W (Ta) · 1.4W · 1.9W (Ta) · 2.03W (Ta) · 2.5W (Ta) · 150mW (Ta) · 730mW (Ta) · 740mW (Ta) · 800mW (Ta) · 900mW (Ta)
- Rds on (Max) @ id, vgs
- 1.1Ohm @ 430mA, 4.5V · 2.2mOhm @ 25A, 10V · 9.5mOhm @ 3.6A, 4.5V · 16mOhm @ 7A, 4.5V · 24mOhm @ 8A, 4.5V · 27mOhm @ 7A, 4.5V · 29mOhm @ 6.4A, 4.5V · 35mOhm @ 4A, 4.5V · 38mOhm @ 5A, 4.5V · 45mOhm @ 4A, 4.5V · 47mOhm @ 1A, 4.5V
Variant comparison
| Parameter | DMP2003UPS-13 | DMP2004TK-7 | DMP2010UFG-7 | DMP2021UFDE-7 | DMP2021UFDF-7 | DMP2023UFDF-7 |
|---|---|---|---|---|---|---|
| Case | 8-PowerTDFN | SOT-523 | 8-PowerVDFN | 6-PowerUDFN | 6-UDFN Exposed Pad | 6-UDFN Exposed Pad |
| Current - continuous drain (Id) @ 25°C | 150A (Tc) | 430mA (Ta) | 12.7A (Ta), 42A (Tc) | 11.1A (Ta) | 9A (Ta) | 7.6A (Ta) |
| Drive voltage (Max rds on, min rds on) | 2.5V, 10V | 1.8V, 4.5V | 2.5V, 4.5V | 1.5V, 4.5V | 1.5V, 4.5V | 1.5V, 4.5V |
| Input capacitance (Ciss) (Max) @ vds | 8352 pF @ 10 V | 175 pF @ 16 V | 3350 pF @ 10 V | 2760 pF @ 15 V | 2760 pF @ 15 V | 1837 pF @ 15 V |
| Operating temperature | -55°C ~ 150°C (TJ) | -55°C~150°C(TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -55°C~150°C(TJ) | -55°C ~ 150°C (TJ) |
| Package | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) |
| Power dissipation | 1.4W | 150mW (Ta) | 900mW (Ta) | 1.9W (Ta) | 730mW (Ta) | 730mW (Ta) |
| Rds on (Max) @ id, vgs | 2.2mOhm @ 25A, 10V | 1.1Ohm @ 430mA, 4.5V | 9.5mOhm @ 3.6A, 4.5V | 16mOhm @ 7A, 4.5V | 16mOhm @ 7A, 4.5V | 27mOhm @ 7A, 4.5V |
Shared specifications
- Drain to source voltage
- 20 V
- FET feature
- -
- FET type
- P-Channel
- Mounting type
- Surface Mount
- Technology
- MOSFET (Metal Oxide)
