74LVC1G06SE-7
Diodes Incorporated
Tape & Reel (TR); Cut Tape (CT)-40°C~125°C74LVC
Ref. price$0.3100
Lead time on requestGet quote ›
Diodes Incorporated 74LVC Series
46 variants · Diodes Incorporated
About the Diodes Incorporated Diodes Incorporated 74LVC Series series
The Diodes Incorporated Diodes Incorporated 74LVC Series series groups 46 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common mounting type of Surface Mount and voltage of 1.65V ~ 5.5V. Variants differ by case, current - output high, low and logic type, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 5-TSSOP, SC-70-5, SOT-353 · 6-XFDFN · SC-74A, SOT-753 · SOT-553
- Current - output high, low
- -, 32mA · 32mA, 32mA
- Logic type
- Buffer, Inverting · Buffer, Non-Inverting · Inverter
- Operating temperature
- -40°C ~ 125°C · -40°C ~ 125°C (TA) · -40°C~125°C · -40°C~125°C(TA)
- Package
- Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT)
- Output type
- 3-State · Open Drain
Variant comparison
| Parameter | 74LVC1G06SE-7 | 74LVC1G06Z-7 | 74LVC1G07FW5-7 | 74LVC1G07SE-7 | 74LVC1G07W5-7 | 74LVC1G125FW4-7 |
|---|---|---|---|---|---|---|
| Case | 5-TSSOP, SC-70-5, SOT-353 | SOT-553 | 6-XFDFN | 5-TSSOP, SC-70-5, SOT-353 | SC-74A, SOT-753 | 6-XFDFN |
| Current - output high, low | -, 32mA | -, 32mA | -, 32mA | -, 32mA | -, 32mA | 32mA, 32mA |
| Logic type | Buffer, Inverting | Inverter | Buffer, Non-Inverting | Buffer, Non-Inverting | Buffer, Non-Inverting | Buffer, Non-Inverting |
| Operating temperature | -40°C~125°C | -40°C ~ 125°C | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) |
| Package | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) |
| Output type | Open Drain | — | Open Drain | Open Drain | Open Drain | 3-State |
Shared specifications
- Mounting type
- Surface Mount
- Voltage
- 1.65V ~ 5.5V
Request a quote on any Diodes Incorporated 74LVC Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Diodes Incorporated Diodes Incorporated 74LVC Series variants differ?
- Diodes Incorporated 74LVC Series part numbers differ by case, current - output high, low, logic type and operating temperature. Use the selection guide above to pick by case.
- How many Diodes Incorporated Diodes Incorporated 74LVC Series part numbers are listed?
- 46 Diodes Incorporated Diodes Incorporated 74LVC Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Diodes Incorporated Diodes Incorporated 74LVC Series?
- Request a quote (RFQ) for any Diodes Incorporated 74LVC Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
