How many Diodes Incorporated Diodes Incorporated 74LV Series part numbers are listed?

86 Diodes Incorporated Diodes Incorporated 74LV Series part numbers are listed, each with specifications and a datasheet where available.

Diodes Incorporated 74LV Series

86 variants · Diodes Incorporated

About the Diodes Incorporated Diodes Incorporated 74LV Series series

The Diodes Incorporated Diodes Incorporated 74LV Series series groups 86 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common mounting type of Surface Mount. Variants differ by case, current - output high, low and current - quiescent, so you can match the exact case your application requires using the selection guide below.

Select a variant by

Case: 5-TSSOP, SC-70-5, SOT-353 · 6-XFDFN · 14-SOIC (0.154\", 3.90mm Width) · 14-TSSOP (0.173\", 4.40mm Width) · SC-74A, SOT-753 · SOT-553
Current - output high, low: 12mA, 12mA · 24mA, 24mA · 32mA, 32mA
Current - quiescent: 4 µA · 10 µA · 20 µA · 200 µA
Features: - · Schmitt Trigger
Input logic level - high: 0.95V ~ 3.4V · 1.7V ~ 2V · 1.75V ~ 3.5V
Input logic level - low: 0.7V ~ 0.8V · 0.75V ~ 1.5V
Logic type: Inverter · NAND Gate · NOR Gate
Max propagation delay @ v, max CL: 1.7ns @ 5V, 50pF · 1.8ns @ 5V, 50pF · 4ns @ 5V, 50pF · 4.3ns @ 3.3V, 50pF · 5.5ns @ 5V, 50pF · 10.6ns @ 5V, 50pF

Variant comparison

Parameter	74LV14AS14-13	74LV14AT14-13	74LVC04AS14-13	74LVC1G00FW5-7	74LVC1G00QSE-7	74LVC1G00QW5-7
Case	14-SOIC (0.154\", 3.90mm Width)	14-TSSOP (0.173\", 4.40mm Width)	14-SOIC (0.154\", 3.90mm Width)	6-XFDFN	5-TSSOP, SC-70-5, SOT-353	SC-74A, SOT-753
Current - output high, low	12mA, 12mA	12mA, 12mA	24mA, 24mA	32mA, 32mA	32mA, 32mA	32mA, 32mA
Current - quiescent	20 µA	20 µA	10 µA	200 µA	4 µA	4 µA
Features	Schmitt Trigger	Schmitt Trigger	-	-	-	-
Input logic level - high	1.75V ~ 3.5V	1.75V ~ 3.5V	1.7V ~ 2V	1.7V ~ 2V	0.95V ~ 3.4V	1.7V ~ 2V
Input logic level - low	0.75V ~ 1.5V	0.75V ~ 1.5V	0.7V ~ 0.8V	0.7V ~ 0.8V	0.7V ~ 0.8V	0.7V ~ 0.8V
Logic type	Inverter	Inverter	Inverter	NAND Gate	NAND Gate	NAND Gate
Max propagation delay @ v, max CL	10.6ns @ 5V, 50pF	10.6ns @ 5V, 50pF	4.3ns @ 3.3V, 50pF	5.5ns @ 5V, 50pF	5.5ns @ 5V, 50pF	5.5ns @ 5V, 50pF

Shared specifications

Mounting type: Surface Mount

Request a quote on any Diodes Incorporated 74LV Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.

Frequently asked questions

How do the Diodes Incorporated Diodes Incorporated 74LV Series variants differ?: Diodes Incorporated 74LV Series part numbers differ by case, current - output high, low, current - quiescent and features. Use the selection guide above to pick by case.
How many Diodes Incorporated Diodes Incorporated 74LV Series part numbers are listed?: 86 Diodes Incorporated Diodes Incorporated 74LV Series part numbers are listed, each with specifications and a datasheet where available.
How do I get pricing and lead time for Diodes Incorporated Diodes Incorporated 74LV Series?: Request a quote (RFQ) for any Diodes Incorporated 74LV Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
