74LVC1G14QSE-7
Diodes Incorporated
1.65V ~ 5.5VTape & Reel (TR) Cut Tape (CT)-40°C ~ 125°C (TA)
Ref. price$0.4300
Lead time on requestGet quote ›
Diodes Incorporated 74LV Series
86 variants · Diodes Incorporated
About the Diodes Incorporated Diodes Incorporated 74LV Series series
The Diodes Incorporated Diodes Incorporated 74LV Series series groups 86 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common mounting type of Surface Mount. Variants differ by case, current - output high, low and current - quiescent, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 5-TSSOP, SC-70-5, SOT-353 · 6-XFDFN · 14-SOIC (0.154\", 3.90mm Width) · 14-TSSOP (0.173\", 4.40mm Width) · SC-74A, SOT-753 · SOT-553
- Current - output high, low
- 12mA, 12mA · 24mA, 24mA · 32mA, 32mA
- Current - quiescent
- 4 µA · 10 µA · 20 µA · 200 µA
- Features
- - · Schmitt Trigger
- Input logic level - high
- 0.95V ~ 3.4V · 1.7V ~ 2V · 1.75V ~ 3.5V
- Input logic level - low
- 0.7V ~ 0.8V · 0.75V ~ 1.5V
- Logic type
- Inverter · NAND Gate · NOR Gate
- Max propagation delay @ v, max CL
- 1.7ns @ 5V, 50pF · 1.8ns @ 5V, 50pF · 4ns @ 5V, 50pF · 4.3ns @ 3.3V, 50pF · 5.5ns @ 5V, 50pF · 10.6ns @ 5V, 50pF
Variant comparison
| Parameter | 74LV14AS14-13 | 74LV14AT14-13 | 74LVC04AS14-13 | 74LVC1G00FW5-7 | 74LVC1G00QSE-7 | 74LVC1G00QW5-7 |
|---|---|---|---|---|---|---|
| Case | 14-SOIC (0.154\", 3.90mm Width) | 14-TSSOP (0.173\", 4.40mm Width) | 14-SOIC (0.154\", 3.90mm Width) | 6-XFDFN | 5-TSSOP, SC-70-5, SOT-353 | SC-74A, SOT-753 |
| Current - output high, low | 12mA, 12mA | 12mA, 12mA | 24mA, 24mA | 32mA, 32mA | 32mA, 32mA | 32mA, 32mA |
| Current - quiescent | 20 µA | 20 µA | 10 µA | 200 µA | 4 µA | 4 µA |
| Features | Schmitt Trigger | Schmitt Trigger | - | - | - | - |
| Input logic level - high | 1.75V ~ 3.5V | 1.75V ~ 3.5V | 1.7V ~ 2V | 1.7V ~ 2V | 0.95V ~ 3.4V | 1.7V ~ 2V |
| Input logic level - low | 0.75V ~ 1.5V | 0.75V ~ 1.5V | 0.7V ~ 0.8V | 0.7V ~ 0.8V | 0.7V ~ 0.8V | 0.7V ~ 0.8V |
| Logic type | Inverter | Inverter | Inverter | NAND Gate | NAND Gate | NAND Gate |
| Max propagation delay @ v, max CL | 10.6ns @ 5V, 50pF | 10.6ns @ 5V, 50pF | 4.3ns @ 3.3V, 50pF | 5.5ns @ 5V, 50pF | 5.5ns @ 5V, 50pF | 5.5ns @ 5V, 50pF |
