MAX3053ASA+
Analog Devices
Tube-40°C ~ 125°CCANbus
Ref. price$5.35
Lead time on requestGet quote
MAX3xxx Analog Switches, Multiplexers & Level Translators — ADI (Maxim)
6 variants · Analog Devices
About the MAX3xxx Analog Switches, Multiplexers & Level Translators — ADI (Maxim)
ICBOMS is a China IC distributor and semiconductor supplier — an independent, Shenzhen-based overseas procurement agent for MAX3xxx Analog Switches, Multiplexers & Level Translators — ADI (Maxim) components — sourcing Analog Devices MAX3xxx Analog Switches, Multiplexers & Level Translators — ADI (Maxim) parts new and original only, across the authorized and vetted independent channel, with every lot authenticity-screened before shipment. The Analog Devices MAX3xxx Analog Switches, Multiplexers & Level Translators — ADI (Maxim) series groups 6 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common mounting of Surface Mount. Variants differ by case, operating temperature and package, so you can match the exact case your application requires using the selection guide below. All listed MAX3xxx Analog Switches, Multiplexers & Level Translators — ADI (Maxim) part numbers are active and orderable.
Select a variant by
- Case
- 8-SOIC (0.154\", 3.90mm Width) · 16-TSSOP (0.173\", 4.40mm Width) · 20-TSSOP (0.173\", 4.40mm Width) · 28-SSOP (0.209\", 5.30mm Width)
- Operating temperature
- -40°C ~ 85°C · -40°C ~ 125°C · 0°C ~ 70°C
- Package
- Tape & Reel (TR); Cut Tape (CT) · Tube
- Type
- Driver · Thermocouple to Digital Converter · Transceiver
- Data rate
- 1Mbps · 2Mbps · 20Mbps · 235Kbps
- Number of drivers (Receivers)
- 1/1 · 2/2 · 3/5 · 4/0
- Protocol
- CANbus · RS232 · RS422, RS485
- Receiver hysteresis
- 150 mV · 300 mV · 500 mV
Shared specifications
- Mounting
- Surface Mount
Variant comparison
| Parameter | MAX3045BCUE+ | MAX3053ASA+ | MAX3053ESA+T | MAX31855NASA+T | MAX3225EUP+ | MAX3241CAI+ |
|---|---|---|---|---|---|---|
| Case | 16-TSSOP (0.173\", 4.40mm Width) | 8-SOIC (0.154\", 3.90mm Width) | 8-SOIC (0.154\", 3.90mm Width) | 8-SOIC (0.154\", 3.90mm Width) | 20-TSSOP (0.173\", 4.40mm Width) | 28-SSOP (0.209\", 5.30mm Width) |
| Operating temperature | 0°C ~ 70°C | -40°C ~ 125°C | -40°C ~ 85°C | -40°C ~ 125°C | -40°C ~ 85°C | 0°C ~ 70°C |
| Package | Tube | Tube | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tube | Tube |
| Type | Driver | Transceiver | Transceiver | Thermocouple to Digital Converter | Transceiver | Transceiver |
| Data rate | 20Mbps | 2Mbps | 2Mbps | — | 1Mbps | 235Kbps |
| Number of drivers (Receivers) | 4/0 | 1/1 | 1/1 | — | 2/2 | 3/5 |
| Protocol | RS422, RS485 | CANbus | CANbus | — | RS232 | RS232 |
| Receiver hysteresis | — | 150 mV | 150 mV | — | 500 mV | 300 mV |
Request a quote on any MAX3xxx Analog Switches, Multiplexers & Level Translators — ADI (Maxim) part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
