Alpha & Omega Semiconductor Inc. AON7 Series

12 variants · Alpha & Omega Semiconductor Inc.

About the Alpha & Omega Semiconductor Inc. Alpha & Omega Semiconductor Inc. AON7 Series series

The Alpha & Omega Semiconductor Inc. Alpha & Omega Semiconductor Inc. AON7 Series series groups 12 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common mounting type of Surface Mount, operating temperature of -55°C ~ 150°C (TJ) and package of Tape & Reel (TR) Cut Tape (CT). Variants differ by case, current - continuous drain (Id) @ 25°C and drain to source voltage, so you can match the exact case your application requires using the selection guide below. All listed Alpha & Omega Semiconductor Inc. AON7 Series part numbers are active and orderable.

Select a variant by

Case
8-PowerSMD, Flat Leads · 8-PowerVDFN · 8-PowerWDFN · 8-WDFN Exposed Pad
Current - continuous drain (Id) @ 25°C
5A (Ta), 12.5A (Tc) · 5.5A (Ta), 17A (Tc) · 6A · 9A (Ta), 23A (Tc) · 9A, 18.5A · 13A, 15A · 21A (Ta), 34A (Tc) · 25A (Ta), 28A (Tc) · 30A (Ta), 50A (Tc) · 32A (Tc) · 34A (Ta), 50A (Tc) · 45A (Ta), 50A (Tc)
Drain to source voltage
20 V · 30 V · 30V · 60 V · 100 V · 150 V
FET feature
- · Logic Level Gate
Gate charge (Qg) (Max) @ vgs
10nC @ 10V · 11nC @ 10V · 12 nC @ 10 V · 12.2nC @ 10V · 20 nC @ 10 V · 25 nC @ 10 V · 45 nC @ 10 V · 50 nC @ 10 V · 60 nC @ 10 V · 114 nC @ 10 V
Input capacitance (Ciss) (Max) @ vds
170pF @ 15V · 415 pF @ 50 V · 485pF @ 15V · 542pF @ 15V · 675 pF @ 75 V · 1170 pF @ 50 V · 1650 pF @ 30 V · 2250 pF @ 15 V · 2300 pF @ 15 V · 2895 pF @ 15 V · 3120 pF @ 15 V · 4550 pF @ 10 V
Rds on (Max) @ id, vgs
2mOhm @ 20A, 10V · 2.8mOhm @ 20A, 10V · 3.3mOhm @ 20A, 10V · 4.6mOhm @ 20A, 10V · 6.2mOhm @ 20A, 10V · 10.2mOhm @ 13A, 10V · 14mOhm @ 6A, 10V · 24mOhm @ 9A, 10V · 50mOhm @ 4A, 10V · 54mOhm @ 5A, 10V · 66mOhm @ 5A, 10V

Variant comparison

ParameterAON7254AON7262EAON7292AON7296AON7421AON7422G
Case8-PowerWDFN8-PowerVDFN8-PowerWDFN8-PowerVDFN8-PowerWDFN8-PowerVDFN
Current - continuous drain (Id) @ 25°C5.5A (Ta), 17A (Tc)21A (Ta), 34A (Tc)9A (Ta), 23A (Tc)5A (Ta), 12.5A (Tc)30A (Ta), 50A (Tc)32A (Tc)
Drain to source voltage150 V60 V100 V100 V20 V30 V
FET feature------
Gate charge (Qg) (Max) @ vgs20 nC @ 10 V45 nC @ 10 V25 nC @ 10 V12 nC @ 10 V114 nC @ 10 V60 nC @ 10 V
Input capacitance (Ciss) (Max) @ vds675 pF @ 75 V1650 pF @ 30 V1170 pF @ 50 V415 pF @ 50 V4550 pF @ 10 V2300 pF @ 15 V
Rds on (Max) @ id, vgs54mOhm @ 5A, 10V6.2mOhm @ 20A, 10V24mOhm @ 9A, 10V66mOhm @ 5A, 10V4.6mOhm @ 20A, 10V4.6mOhm @ 20A, 10V

Shared specifications

Mounting type
Surface Mount
Operating temperature
-55°C ~ 150°C (TJ)
Package
Tape & Reel (TR) Cut Tape (CT)
Technology
MOSFET (Metal Oxide)

Request a quote on any Alpha & Omega Semiconductor Inc. AON7 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
