AON6152A
Alpha & Omega Semiconductor Inc.
Tape & Reel (TR) Cut Tape (CT)-55°C ~ 150°C (TJ)AlphaSGT™
Ref. price$2.6000
Lead time on requestGet quote ›
Alpha & Omega Semiconductor Inc. AON6 Series
16 variants · Alpha & Omega Semiconductor Inc.
About the Alpha & Omega Semiconductor Inc. Alpha & Omega Semiconductor Inc. AON6 Series series
The Alpha & Omega Semiconductor Inc. Alpha & Omega Semiconductor Inc. AON6 Series series groups 16 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common FET feature of -, FET type of N-Channel and mounting type of Surface Mount. Variants differ by case, current - continuous drain (Id) @ 25°C and drain to source voltage, so you can match the exact case your application requires using the selection guide below. All listed Alpha & Omega Semiconductor Inc. AON6 Series part numbers are active and orderable.
Select a variant by
- Case
- 8-PowerSMD, Flat Leads · 8-PowerVDFN
- Current - continuous drain (Id) @ 25°C
- 13.5A (Ta), 52A (Tc) · 14A (Ta), 24A (Tc) · 17A (Ta), 85A (Tc) · 18.5A (Ta), 85A (Tc) · 24A (Ta), 78A (Tc) · 24A (Tc) · 34A (Ta), 85A (Tc) · 44A (Tc) · 58A (Ta), 100A (Tc) · 83A (Tc) · 85A (Tc) · 100A (Tc)
- Drain to source voltage
- 30 V · 45 V · 60 V · 80 V · 150 V
- Drive voltage (Max rds on, min rds on)
- 4.5V, 10V · 6V, 10V · 10V
- Gate charge (Qg) (Max) @ vgs
- 10 nC @ 4.5 V · 10 nC @ 10 V · 35 nC @ 10 V · 40 nC @ 10 V · 43 nC @ 10 V · 65 nC @ 10 V · 72 nC @ 10 V · 82 nC @ 10 V · 86 nC @ 10 V · 100 nC @ 10 V · 155 nC @ 10 V
- Input capacitance (Ciss) (Max) @ vds
- 670 pF @ 15 V · 755 pF @ 30 V · 1330 pF @ 15 V · 2162 pF @ 40 V · 2388 pF @ 75 V · 2520 pF @ 30 V · 3100 pF @ 15 V · 3930 pF @ 40 V · 4646 pF @ 40 V · 4940 pF @ 40 V · 6370 pF @ 30 V · 10000 pF @ 22.5 V
- Operating temperature
- -55°C ~ 150°C (TA) · -55°C ~ 150°C (TJ) · -55°C~150°C(TJ)
- Package
- Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT)
Variant comparison
| Parameter | AON6152A | AON6204 | AON6242 | AON6250 | AON6266E | AON6268 |
|---|---|---|---|---|---|---|
| Case | 8-PowerSMD, Flat Leads | 8-PowerSMD, Flat Leads | 8-PowerSMD, Flat Leads | 8-PowerSMD, Flat Leads | 8-PowerVDFN | 8-PowerSMD, Flat Leads |
| Current - continuous drain (Id) @ 25°C | 58A (Ta), 100A (Tc) | 14A (Ta), 24A (Tc) | 18.5A (Ta), 85A (Tc) | 13.5A (Ta), 52A (Tc) | 24A (Tc) | 44A (Tc) |
| Drain to source voltage | 45 V | 30 V | 60 V | 150 V | 60 V | 60 V |
| Drive voltage (Max rds on, min rds on) | 4.5V, 10V | 4.5V, 10V | 4.5V, 10V | 6V, 10V | 4.5V, 10V | 10V |
| Gate charge (Qg) (Max) @ vgs | 155 nC @ 10 V | 10 nC @ 10 V | 72 nC @ 10 V | 43 nC @ 10 V | 10 nC @ 4.5 V | 65 nC @ 10 V |
| Input capacitance (Ciss) (Max) @ vds | 10000 pF @ 22.5 V | 670 pF @ 15 V | 6370 pF @ 30 V | 2388 pF @ 75 V | 755 pF @ 30 V | 2520 pF @ 30 V |
| Operating temperature | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -55°C~150°C(TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TA) |
| Package | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) |
Shared specifications
- FET feature
- -
- FET type
- N-Channel
- Mounting type
- Surface Mount
- Technology
- MOSFET (Metal Oxide)
- Vgs
- ±20V
