PTCCL10H010SBE
Vishay Beyschlag/Draloric/BC Components
PTCCL - 600V0.532\" (13.50mm)-20°C~85°C
Ref. price$2.7500
Lead time on requestGet quote
Vishay Beyschlag/Draloric/BC Components PTCCL1 Series
29 variants · Vishay Beyschlag/Draloric/BC Components
About the Vishay Beyschlag/Draloric/BC Components PTCCL1 Series
The Vishay Beyschlag/Draloric/BC Components PTCCL1 Series series groups 29 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common case of Radial, Disc, mounting of Through Hole and ratings of -. Variants differ by approval agency, current - hold (Ih) and current - max, so you can match the exact approval agency your application requires using the selection guide below.
Select a variant by
- Approval agency
- UL · UR
- Current - hold (Ih)
- 10 mA · 210 mA · 250 mA · 280 mA · 320 mA · 610 mA · 700 mA
- Current - max
- 1.3 A · 1.5 A · 1.8 A · 2 A · 3 A · 7 A · 8 A
- Current - trip
- 1.05 A · 50 mA · 315 mA · 375 mA · 420 mA · 480 mA · 915 mA
- Height - seated
- 0.532\" (13.50mm) · 0.606\" (15.40mm) · 0.610\" (15.50mm) · 0.689\" (17.50mm)
- Lead spacing
- 0.197\" (5.00mm) · 0.320\" (8.12mm)
- Operating temperature
- -40°C ~ 85°C · -40°C~85°C · -20°C~85°C · 0°C ~ 70°C · 0°C~70°C
- Package
- Bulk · Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT)
Shared specifications
- Case
- Radial, Disc
- Mounting
- Through Hole
- Ratings
- -
- Thickness
- -
- Type
- Ceramic
Variant comparison
| Parameter | PTCCL10H010SBE | PTCCL11H211HBE | PTCCL11H211HTE | PTCCL11H251HBE | PTCCL11H251HTE | PTCCL11H321FBE |
|---|---|---|---|---|---|---|
| Approval agency | UL | UR | UR | UR | UR | UR |
| Current - hold (Ih) | 10 mA | 210 mA | 210 mA | 250 mA | 250 mA | 320 mA |
| Current - max | 2 A | 1.3 A | 1.3 A | 1.5 A | 1.5 A | 3 A |
| Current - trip | 50 mA | 315 mA | 315 mA | 375 mA | 375 mA | 480 mA |
| Height - seated | 0.532\" (13.50mm) | 0.610\" (15.50mm) | 0.610\" (15.50mm) | 0.610\" (15.50mm) | 0.610\" (15.50mm) | 0.610\" (15.50mm) |
| Lead spacing | 0.320\" (8.12mm) | 0.197\" (5.00mm) | 0.197\" (5.00mm) | 0.197\" (5.00mm) | 0.197\" (5.00mm) | 0.197\" (5.00mm) |
| Operating temperature | -20°C~85°C | 0°C ~ 70°C | 0°C~70°C | 0°C~70°C | 0°C ~ 70°C | 0°C~70°C |
| Package | Bulk | Bulk | Tape & Reel (TR); Cut Tape (CT) | Bulk | Tape & Reel (TR) Cut Tape (CT) | Bulk |
Request a quote on any Vishay Beyschlag/Draloric/BC Components PTCCL1 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
