LP2950-30LP
Texas Instruments
Bulk-40°C~125°C(TJ)Fixed
Ref. price$1.1000
Lead time on requestGet quote ›
Texas Instruments LP29 Series
358 variants · Texas Instruments
About the Texas Instruments Texas Instruments LP29 Series series
The Texas Instruments Texas Instruments LP29 Series series groups 358 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common control features of -, current - output of 100mA and current - quiescent of 120 µA. Variants differ by case, mounting type and operating temperature, so you can match the exact case your application requires using the selection guide below. The range mixes active and legacy part numbers, so you can source both current Texas Instruments LP29 Series variants and discontinued ones from a single page.
Select a variant by
- Case
- TO-226-3, TO-92-3 (TO-226AA) · TO-226-3, TO-92-3 (TO-226AA) Formed Leads · TO-252-3, DPak (2 Leads + Tab), SC-63
- Mounting type
- Surface Mount · Through Hole
- Operating temperature
- -40°C ~ 125°C · -40°C ~ 125°C (TJ) · -40°C~125°C · -40°C~125°C(TJ)
- Package
- Bulk · Cut Tape (CT); Tape & Box (TB) · Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT) · Tube
- Protection features
- Over Current, Over Temperature · Over Current, Over Temperature, Short Circuit
- Voltage - output (Min (Fixed))
- 3V · 3.3V · 5V
Variant comparison
| Parameter | LP2950-30LP | LP2950-30LPR | LP2950-30LPRE3 | LP2950-50LPRE3 | LP2950ACZ-3.0/NOPB | LP2950ACZ-3.3/NOPB |
|---|---|---|---|---|---|---|
| Case | TO-226-3, TO-92-3 (TO-226AA) | TO-226-3, TO-92-3 (TO-226AA) Formed Leads | TO-226-3, TO-92-3 (TO-226AA) Formed Leads | TO-226-3, TO-92-3 (TO-226AA) Formed Leads | TO-226-3, TO-92-3 (TO-226AA) | TO-226-3, TO-92-3 (TO-226AA) |
| Mounting type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Operating temperature | -40°C~125°C(TJ) | -40°C~125°C(TJ) | -40°C~125°C(TJ) | -40°C~125°C(TJ) | -40°C~125°C | -40°C~125°C |
| Package | Bulk | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Bulk | Bulk |
| Protection features | Over Current, Over Temperature | Over Current, Over Temperature, Short Circuit | Over Current, Over Temperature, Short Circuit | Over Current, Over Temperature | Over Current, Over Temperature | Over Current, Over Temperature |
| Voltage - output (Min (Fixed)) | 3V | 3V | 3V | 5V | 3V | 3.3V |
Shared specifications
- Control features
- -
- Current - output
- 100mA
- Current - quiescent
- 120 µA
- Current - supply
- 14 mA
- Number of regulators
- 1
- Output configuration
- Positive
- Output type
- Fixed
- PSRR
- -
- Voltage - input
- 30V
- Voltage - output
- -
- Voltage dropout
- 0.6V @ 100mA
Request a quote on any Texas Instruments LP29 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Texas Instruments Texas Instruments LP29 Series variants differ?
- Texas Instruments LP29 Series part numbers differ by case, mounting type, operating temperature and package. Use the selection guide above to pick by case.
- How many Texas Instruments Texas Instruments LP29 Series part numbers are listed?
- 358 Texas Instruments Texas Instruments LP29 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Texas Instruments Texas Instruments LP29 Series?
- Request a quote (RFQ) for any Texas Instruments LP29 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
