Taiwan Semiconductor Corporation RS1G Series

5 variants · Taiwan Semiconductor Corporation

About the Taiwan Semiconductor Corporation Taiwan Semiconductor Corporation RS1G Series series

The Taiwan Semiconductor Corporation Taiwan Semiconductor Corporation RS1G Series series groups 5 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common mounting type of Surface Mount, reverse recovery time of 150 ns and speed of Fast Recovery =< 500ns, > 200mA (Io). Variants differ by capacitance @ vr, f, case and current - average rectified, so you can match the exact capacitance @ vr, f your application requires using the selection guide below. All listed Taiwan Semiconductor Corporation RS1G Series part numbers are active and orderable.

Select a variant by

Capacitance @ vr, f: - · 7pF @ 4V, 1MHz · 10pF @ 4V, 1MHz
Case: DO-219AB · DO-221AC, SMA Flat Leads · SOD-123W · SOD-128
Current - average rectified: 1A · 800mA
Current - reverse leakage @ vr: 1 µA @ 400 V · 5 µA @ 400 V
Operating temperature - junction: -55°C ~ 150°C · -55°C ~ 175°C · -55°C~150°C
Package: Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT)
Voltage - forward (Vf) (Max) @ if: 1.3 V @ 1 A · 1.3 V @ 800 mA

Variant comparison

Parameter	RS1GFSHMWG	RS1GFS MWG	RS1GL RVG	RS1GLWHRVG	RS1GAL
Capacitance @ vr, f	7pF @ 4V, 1MHz	7pF @ 4V, 1MHz	10pF @ 4V, 1MHz	-	7pF @ 4V, 1MHz
Case	SOD-128	SOD-128	DO-219AB	SOD-123W	DO-221AC, SMA Flat Leads
Current - average rectified	1A	1A	800mA	1A	1A
Current - reverse leakage @ vr	5 µA @ 400 V	5 µA @ 400 V	5 µA @ 400 V	5 µA @ 400 V	1 µA @ 400 V
Operating temperature - junction	-55°C ~ 150°C	-55°C~150°C	-55°C~150°C	-55°C ~ 175°C	-55°C~150°C
Package	Tape & Reel (TR) Cut Tape (CT)	Tape & Reel (TR); Cut Tape (CT)	Tape & Reel (TR); Cut Tape (CT)	Tape & Reel (TR) Cut Tape (CT)	Tape & Reel (TR); Cut Tape (CT)
Voltage - forward (Vf) (Max) @ if	1.3 V @ 1 A	1.3 V @ 1 A	1.3 V @ 800 mA	1.3 V @ 1 A	1.3 V @ 1 A

Shared specifications

Mounting type: Surface Mount
Reverse recovery time: 150 ns
Speed: Fast Recovery =< 500ns, > 200mA (Io)
Voltage - DC reverse (Vr): 400 V
