SMP1307-011LF
Skyworks Solutions
-65°C ~ 150°C (TA)Tape & Reel (TR); Cut Tape (CT)PIN - Single
Ref. price$0.91
Lead time on requestGet quote ›
Skyworks Solutions SMP13 Series
26 variants · Skyworks Solutions
About the Skyworks Solutions Skyworks Solutions SMP13 Series series
The Skyworks Solutions Skyworks Solutions SMP13 Series series groups 26 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common package of Tape & Reel (TR); Cut Tape (CT). Variants differ by capacitance @ vr, f, case and diode type, so you can match the exact capacitance @ vr, f your application requires using the selection guide below.
Select a variant by
- Capacitance @ vr, f
- 0.2pF @ 5V, 1MHz · 0.25pF @ 30V, 1MHz · 0.3pF @ 30V, 1MHz · 1pF @ 0V, 1MHz · 1pF @ 30V, 1MHz
- Case
- 2-VDFN Exposed Pad · 0402 (1005 Metric) · SC-76, SOD-323 · SC-79, SOD-523 · TO-236-3, SC-59, SOT-23-3
- Diode type
- PIN - Single · Standard - 1 Pair Series Connection
- Operating temperature
- -65°C ~ 150°C (TA) · 175°C (TJ)
- Power dissipation
- 3 W · 250 mW · 750 mW
- Resistance @ if, f
- 1.5Ohm @ 10mA, 100MHz · 2Ohm @ 10mA, 100MHz · 3Ohm @ 100mA, 100MHz · 500mOhm @ 10mA, 100MHz · 900mOhm @ 10mA, 100MHz
- Voltage - peak reverse
- 20V · 50V · 100V · 200V
- Current - max
- 100 mA · 150 mA · 200 mA
Variant comparison
| Parameter | SMP1307-011LF | SMP1320-040LF | SMP1321-040LF | SMP1321-079LF | SMP1322-079LF | SMP1330-005LF |
|---|---|---|---|---|---|---|
| Capacitance @ vr, f | 0.3pF @ 30V, 1MHz | 0.25pF @ 30V, 1MHz | 0.25pF @ 30V, 1MHz | 0.25pF @ 30V, 1MHz | 1pF @ 30V, 1MHz | 1pF @ 0V, 1MHz |
| Case | SC-76, SOD-323 | 0402 (1005 Metric) | 0402 (1005 Metric) | SC-79, SOD-523 | SC-79, SOD-523 | TO-236-3, SC-59, SOT-23-3 |
| Diode type | PIN - Single | PIN - Single | PIN - Single | PIN - Single | PIN - Single | Standard - 1 Pair Series Connection |
| Operating temperature | -65°C ~ 150°C (TA) | -65°C ~ 150°C (TA) | -65°C ~ 150°C (TA) | -65°C ~ 150°C (TA) | -65°C ~ 150°C (TA) | -65°C ~ 150°C (TA) |
| Power dissipation | 250 mW | 750 mW | 750 mW | 250 mW | 250 mW | 250 mW |
| Resistance @ if, f | 3Ohm @ 100mA, 100MHz | 900mOhm @ 10mA, 100MHz | 2Ohm @ 10mA, 100MHz | 2Ohm @ 10mA, 100MHz | 500mOhm @ 10mA, 100MHz | 1.5Ohm @ 10mA, 100MHz |
| Voltage - peak reverse | 200V | 50V | 100V | 100V | 50V | 20V |
| Current - max | — | 150 mA | 150 mA | — | — | 100 mA |
