RCLAMP01211ZCFT
Semtech Corporation
Surface MountTape & Reel (TR) Cut Tape (CT)Zener
Ref. price$0.4100
Lead time on requestGet quote
Semtech Corporation RCLAMP Series
127 variants · Semtech Corporation
About the Semtech Corporation RCLAMP Series
The Semtech Corporation RCLAMP Series series groups 127 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common mounting of Surface Mount. Variants differ by applications, capacitance @ frequency and case, so you can match the exact applications your application requires using the selection guide below. The range mixes active and legacy part numbers, so you can source both current Semtech Corporation RCLAMP Series variants and discontinued ones from a single page.
Select a variant by
- Applications
- Automotive, Ethernet · Ethernet, HDMI · General Purpose · HDMI2, USB 3.2 · USB · USB OTG
- Capacitance @ frequency
- - · 0.28pF @ 1MHz · 0.3pF @ 1MHz · 0.55pF @ 1MHz · 0.9pF @ 1MHz · 1.1pF @ 1MHz · 1.2pF @ 1MHz · 1.7pF @ 1MHz · 3pF @ 1MHz
- Case
- 3-DFN · 5-TSSOP, SC-70-5, SOT-353 · 6-TSSOP, SC-88, SOT-363 · 6-UFDFN · 10-UFDFN · 0201 (0603 Metric) · 0402 (1006 Metric) · SC-75, SOT-416 · SOT-563, SOT-666
- Current - peak pulse (10/1000μs)
- - · 2.5A (8/20µs) · 3A (8/20µs) · 5A (8/20µs) · 6A (8/20µs) · 8A (8/20µs) · 10A (8/20µs) · 28A (8/20µs)
- Operating temperature
- - · -55°C ~ 125°C (TJ) · -55°C~125°C(TJ) · -40°C ~ 85°C (TA) · -40°C ~ 125°C (TJ)
- Package
- Tape & Reel (TR) · Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT)
- Power - peak pulse
- - · 45W · 50W · 70W · 100W · 125W · 150W · 500W
- Power line protection
- No · Yes
Shared specifications
- Mounting
- Surface Mount
Variant comparison
| Parameter | RCLAMP01211ZCFT | RCLAMP01811ZA.F | RCLAMP01892PWQC | RCLAMP03354P.C | RCLAMP0501T.TNT | RCLAMP0502A.TCT |
|---|---|---|---|---|---|---|
| Applications | USB | General Purpose | Automotive, Ethernet | HDMI2, USB 3.2 | General Purpose | Ethernet, HDMI |
| Capacitance @ frequency | - | 0.55pF @ 1MHz | - | 0.28pF @ 1MHz | 1.7pF @ 1MHz | 0.9pF @ 1MHz |
| Case | 0201 (0603 Metric) | 0201 (0603 Metric) | 3-DFN | 10-UFDFN | 0402 (1006 Metric) | SOT-563, SOT-666 |
| Current - peak pulse (10/1000μs) | - | 8A (8/20µs) | 2.5A (8/20µs) | 10A (8/20µs) | 10A (8/20µs) | 3A (8/20µs) |
| Operating temperature | - | -40°C ~ 85°C (TA) | - | -40°C ~ 125°C (TJ) | -55°C ~ 125°C (TJ) | -55°C~125°C(TJ) |
| Package | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) |
| Power - peak pulse | - | 45W | - | 70W | 150W | 50W |
| Power line protection | No | No | No | No | No | Yes |
Request a quote on any Semtech Corporation RCLAMP Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
