Power Integrations TOP26 Series
20 variants · Power Integrations
About the Power Integrations Power Integrations TOP26 Series series
The Power Integrations Power Integrations TOP26 Series series groups 20 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common duty cycle of 78%, internal switch of Yes and output isolation of Isolated. Variants differ by case, control features and fault protection, so you can match the exact case your application requires using the selection guide below. All listed Power Integrations TOP26 Series part numbers are active and orderable.
Select a variant by
- Case
- 7-SSIP, 6 Leads, Exposed Pad, Formed Leads · 12-BESOP (0.350\", 8.89mm Width), 11 Leads, Exposed Pad · 12-SDIP (0.412\", 10.46mm), 11 Leads, Exposed Pad · TO-220-7 Formed Leads, 6 Leads
- Control features
- - · Frequency Control
- Fault protection
- Current Limiting, Over Load, Over Temperature, Over Voltage, Short Circuit · Current Limiting, Over Temperature, Over Voltage
- Frequency
- 66kHz · 66kHz, 132kHz
- Mounting type
- Surface Mount · Through Hole
- Operating temperature
- -40°C ~ 150°C (TJ) · -40°C~150°C(TJ)
- Package
- Tape & Reel (TR); Cut Tape (CT) · Tube
- Power (Watts)
- 34 W · 49 W · 53 W · 58 W · 62 W · 81 W · 119 W · 275 W · 333 W
Variant comparison
| Parameter | TOP260EN | TOP261EG | TOP261EN | TOP261YN | TOP262EN | TOP264EG |
|---|---|---|---|---|---|---|
| Case | 7-SSIP, 6 Leads, Exposed Pad, Formed Leads | 7-SSIP, 6 Leads, Exposed Pad, Formed Leads | 7-SSIP, 6 Leads, Exposed Pad, Formed Leads | TO-220-7 Formed Leads, 6 Leads | 7-SSIP, 6 Leads, Exposed Pad, Formed Leads | 7-SSIP, 6 Leads, Exposed Pad, Formed Leads |
| Control features | - | - | - | - | - | Frequency Control |
| Fault protection | Current Limiting, Over Temperature, Over Voltage | Current Limiting, Over Temperature, Over Voltage | Current Limiting, Over Temperature, Over Voltage | Current Limiting, Over Temperature, Over Voltage | Current Limiting, Over Temperature, Over Voltage | Current Limiting, Over Load, Over Temperature, Over Voltage, Short Circuit |
| Frequency | 66kHz, 132kHz | 66kHz, 132kHz | 66kHz, 132kHz | 66kHz | 66kHz, 132kHz | 66kHz, 132kHz |
| Mounting type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Operating temperature | -40°C ~ 150°C (TJ) | -40°C~150°C(TJ) | -40°C~150°C(TJ) | -40°C~150°C(TJ) | -40°C~150°C(TJ) | -40°C~150°C(TJ) |
| Package | Tube | Tube | Tube | Tube | Tube | Tube |
| Power (Watts) | 275 W | 333 W | 333 W | 333 W | 333 W | 62 W |
Shared specifications
- Duty cycle
- 78%
- Internal switch
- Yes
- Output isolation
- Isolated
- Topology
- Flyback
- Voltage - supply (Vcc (Vdd))
- -
